Фрезерный сверлильный станок CNC с

◆ The machine is suitable for processing installation holes, water slot, shaped holes, and end milling and making screw on curtain walls and aluminum windows and doors.

◆ It adopts high-speed electric principal axis, which is imported from Italy. It is extremely efficient and can swing in±90°

◆ It adopts high-quality computer control system which is used in industry area specially, with good user interface, graphical programming and processing tracking interface, truly realize what you see and what you get.

◆ It adopts high-quality servo motor, ball screw, linear guide pair and bearings and so on to ensure the machine runs with high precision.

◆ Equipped Six cutters positions, the cutter can change quickly and automatically .

◆ The semi-closed guard improved security greatly.

◆ Clamping device position can be optimized and put to right position automatically and freely.

Name: 4 axis CNC machining center

Model: DMCC6

Power: 380V/50Hz/10kw

Air pressure: 0.5-0.8Mpa

X axis stroke: 7600mm

X axis speed: 0-90m/min

Y axis stroke: 960mm

Y axis speed: 0-80m/min

Z axis stroke: 610mm

Z axis speed: 0-75m/min

Max. speed: 18000RPM

Spindle rotation range: -90°- 0°-90°

Tool magazine: 6 tools, automatic changing

Max. length of tool: 165mm

Clamping station: 8

Lubrication and cooling: Automatic lubrication and spray cooling

Max. size of profile(WxHxL): 550mm x 300mm x 7300mm

Overall dimension(LxWxH): 10100x2300x2600mm

One:PARKER Introduce

1.PARKER Machinery Co.,LTD was founded in 2003,since the entry into the window door curtain wall machinery manufacturing field,peck with the best team and most stringent manufacturing standards,has been committed to the global supply of machinery and the best service.Today,with more than 300 employees,PARKER Industrial Park covers an area of 70000 m^2,Parker has become Chinese and even the world's window door curtain wall and insulating glass high-end machinery manufacturing base.

2.PARKER products include aluminium,PVC window and doors machinery,aluminium curtain wall processing machinery,industrial aluminium processing machinery and insulating glass series production line machinery.

3.PARKER machinery expotrs to the world more than 80 countries and regions,and has firstly established branches in USA,India,UAE,Brazil,has more than 15 patents.

4.PARKER machinery are all passed through high standard European CE certification,American UL certification and Canadian CSA certification.

5.PARKER manufacturing creates ecological management system of 9M that is unique and most proud of,and the human resources,raw materials,technology methods,environment,information etc. Have been ongoing ascension,and improves the overall quality and core competitiveness of parker.Customers around the world are actively popularize and apply it,benefit a lot from it.

6.PARKER machine core parts procurement achieved internationalization,and established a cooperative partnership with ABBA,OMRON,SCHNEIDER,OPTIMA.

7.PARKER people are always follow the core concept,it is "PARKER is developing with the world",it is PARKER peoples' strict implementation of ecological system of PAREKR and of "zero defect" stern pursuit,which makes the PARKER machine perfect implement unique global standard,achieves improvement value and sustainable innovation!

8.PARKER machinery,leads the era of intelligence,create the strategy of globalization!

9.PARKER machinery,contribution to the world culture of windows and doors!

Two:PARKER Core Concept

1,The core concept of PARKER: PARKER is developing with the world

2,Parker's mission: Making machines to be partners

3,Parker's spirit:High-quality being the aim, foresight win the world

4,Parker's strategy:Open intelligent era and create world famous brand

Three:PARKER Factory

Four:PARKER Factory Store Room

Five:PARKER Family

Six:PARKER Meeting Room

Seven:PARKER Cooperative Partner

Eight:PARKER CE Certification
