EN877 hubless чугунный фитинг для труб характеристики из ковкого

Standard

ASTM A888

Origin

Hebei, China.

Brand

LINO & OEM

Material

grey cast iron

Size

1.5''-15''

Length/PC

3.048M

Thickness

1.5'': 3.3-4.0mm

2'': 3.3-4.0mm

3'': 3.3-4.0mm

4'': 3.81-4.81mm

5'':3.81-4.81mm

6'': 3.81-4.83mm

8'': 4.32-5.84mm

10'': 5.59-7.44mm

12'': 5.59-7.44mm

Inside Diameter

1.5'': 38.1+/-2.29mm

2'': 49.8+/-2.29mm

3'': 75.2+/-2.29mm

4'':100.08+/-2.29mm

5'': 125.48+/-2.29mm

6'': 150.88+/-2.29mm

8'': 201.68+/-3.3mm

10'': 254+/-3.3mm

12'': 303.28+/-2.29mm

Outside Diameter

1.5'': 48.26+/-1.52mm

2'': 59.69+/-2.29mm

3'': 85.09+/-2.29mm

4'':109.98-113.54mm

5'': 133.55-136.91mm

6'': 158.75-162.31mm

8'': 210.56-216.15mm

10'': 268.22+/-2.29mm

12'': 317.50+/-2.29mm

Paint

black bitumen paint

Packing  QTY

1.5'': 82pcs/pallet

2'':66pcs/pallet

3'':58pcs/pallet

4'': 34pcs/pallet

5'': 20pcs/pallet

6'': 17pcs/pallet

8'': 14pcs/pallet

10'': 8 pcs/pallet

Approval

UPC approval

MOQ

1X40'GP
