CIMC 3 оси забора скота животных смежный трейлер для

Type:

CIMC 3 axle fence livestock animal transport semi trailer for sale

Model:

ZJV9400DY

Dimension:

Length:

12,500mm

Width:

2,500mm

Height:

1,500mm

Kingpin location:

1,100mm from the front face of the front bolster

Axle spacer:

6,830mm+1,310mm+1,310mm

Landing gear location

2,650mm behind the kingpin location

Weight:

Payload:

40,000kg

Tare weight:

Approx. 7,800kg

G.V.W.R.:

Approx. 47,800kg

Frame & Structure:

Main beam:

Material Q345B. Fabricated “H” beam height 500mm, Top flange thickness 12mm, Middle web thickness 6mm, Bottom flange thickness 14mm

Side beam:

14# channel steel

Platform:

2.5mm thick chequer plate with supporting channel

Side wall:

Corrugated plate, height 600mm

Cross beam:

80*40mm square tube

Kingpin:

JOST 2”SAE Kingpin, bolted in type

Twist lock:

Without (Can be optional)

Welding standard:

All welding are to be done by qualified welder per applicable national standard

Painting:

Shot blast at Standard SA 2.5 prior to application of primer, polyurethane top coat. Total DFT not less than 100um

Running gear:

Suspension:

JMCG mechanical suspension, leaf spring 13mmx90mm, China

Axle:

FUWA 150x150 square beam axle, 3pcs*13 ton capacity, China

Brake system:

Dual line pneumatic brake, SAE hose and connector

Brake chamber:

4 units T30/30 spring brake chambers, 2 units T30 brake chambers

Air tank:

40L, 2 pcs, China

Emergency relay valve:

Wabco relay valve

Tire:

Triangle brand, 12R22.5, 12 pcs. China

Rim:

9.00*22.5 steel disc wheel, 10 holes ISO, 12 pcs. China

Landing gear:

JOST C200 two speed telescopic manual landing gear

Electrical System:

Voltage:

24 Volt

Receptacle:

7 way socket SAE standard, China

Front marker lamp:

White

Side marker lamp:

White & Red

Rear lamp:

Red

Turn signal lamp:

Amber

Reflector:

Per customer requirement

Wiring:

Electric cable protected by PVC conduit on main frame

Accessories:

Mud guard:

Steel mud guard

Spare wheel carriers:

2 pcs

Tool box:

1 pc
