CE certificated Z Blade Kneader /Sigma rubber mixer



This machine widely used in soap, plastic, rubber, silicon, paint, printing ink, basoid, carbon, food stuff, medicine etc, Mixing Bowl and agitating valve are all made by stainless steel, The jacket of mixing bowl can be designed into electric heating, steam heating, steam heating or water cooling. Discharge ways as hydraulic flanging, screw extruder and botton discharge etc.

Widely used in high viscosity product

------Chemicals Industry:

 Resins, Sealant, silicon rubber, glue/ adhesive, paint, dye, BMC/CMC, pigment,  plastics,  batteries.



------Food Industry:



Bubble gum, dough, chewing gum,  soft candy,  cheese etc.



------Pharmaceutical:

Some medicines  &  medical materials.



Discharge Way:hydraulic tilt,screw extruding,bottom valve.

Funcation:         can be cooling or heating(electrical,cycle hot water/oil).

Type:                  normal type, pressure type, vacuum type.

Material:           can be SS304,SS316 or carbon steel.

Speed:                can be controlled by frequency converter,or fixed.

Blades&Chamber:will be fine polished.





Specification:



Model		NH-5	NH-40	NH-100	NH-300	NH-500	NH-1000	NH-1500	NH-2000
Volume(L)		5	40	100	300	500	1000	1500	2000
Rotor Speed(rpm)		33 / 23	45/23	35/22	37/21	37/21	35/25	30/16	45/30
motor(kw)		0.75	2.2	3/4/5.5	7.5/11	15/18.5	22/30/37/45	22/30/37	45
Heating way	Vapor: pressure(MPa)	0.3
	Electric heating: power(kw)	1	4	4	6	16.2	25	32.4	-
Vacuum(MPa)		0.094(vacuum kneader)
dimension(mm)		0.45(pressure model kneader)				0.35(pressure type kneader)
		650* 400* 705	1170* 1100* 480	1645* 775* 1540	1800* 800* 1400	3000* 1000* 1500	3450* 1300* 1600	3600* 1420* 1800	3900* 1600* 2100
Weight(kg)		300	560	1250	1600	3000	4500	5800	6500
