DR5000 aquaculture online multi parameter water analyzer

Product Overview



DR-5000 multi-parameter water analyzer is a highly integrated measured parameter wall-mounted equipment which can test the parameter all in one, compact structure, with input probe, with high degree of intelligence and flexibility, widely used in water supply, municipal, farming and other industries.





II Feature



1. Can be connected with an analog or digital sensor, readily assembled into a conventional five-parameter water quality analysis instrument.
2. DC12V can supply current of less than 500mA, can use solar powered.
3. Controller whole intelligent, automatic identification of sensor.
4. Display the SD card storage data on the computer.
5. Can calibrate the sensor both in the scene and in the lab.
6. 4.3-inch LCD display, showing beautiful, easy manipulation, can display multiple parameters in the same time.
7. With power protection and automatic recovery function call, parameter settings after power is not lost.
8. No reagent filling, no reagent consumption.









Parameter/Feature	Temperature	PH / ORP Sensor	Dissolved Oxygen Sensor	Conductivity Sensor	Turbidity Sensor	Residual Chlorine Sensor
Measuring principle	platinum resistance temperature sensor	glass electrode method	Fluorescence	Electromagnetic induction method	90 ° near-infrared light scattering beam testing	Constant voltage method
Measuring Range	-10 ~ 150 ℃	-2000 ~ + 2000mv / -2 ~ 14 pH	0 ~20.00 mg/L, -5 ~60℃	0~200/0~2,000,000mS/cm	0.001-4000NTU	0~5.00ppm(HClO) 0~5.00ppm(ClO2)
Sensitivity		≤ ± 0.5mV / ± 0.01 pH
ATC Range		0 ~ 105 ℃	0 ~ 50℃	-20 ~100℃
Response Time		<50 seconds	60 seconds	<60 seconds		<1 min (90%, 20℃)
Accuracy	± 0.2 ℃		≤0.1 mg/L	±0.01 % of reading	±0.5%FSD	2%F.S(0~5.00ppm)
Resolution			≤0.01 mg/L		≤0.01NTU or 0.1NTU	0.01 ppm
Repeatability			0.05mg/L	±1%
Installation Type	submerged, with a mounting bracket	Immersion Type with fixed mounting bracket	Immersion Type with fixed mounting bracket	Immersion or Piping Type with fixed mounting bracket		flow type



 Application



Packing and Delivery





 Welcome to our factory.

Yantai dongrun Instrument Co., Ltd. was founded in 1998, specializes in manufacturing online water quality analysis equipment, High precise Online Turbidity Analyzer , material level meters, pressure gauges, flow meters, special temperature gauges and laboratory analysis equipment. Our company cooperate with the Chinese Academy of Sciences to build a water analysis laboratory, and the main products are TOC analyzer, ammonia analyzer, fluorescence oxygen analyzer, etc. We have passed the ISO9001 certification and has a professional R & D team, providing technical support to meet customer demand, particularly in the anti-corrosion, our company has a unique technology to meet different conditions of corrosion requirements.
