Кабель электропитания 0,75-10 мм2, Электрический кабель
US $0.45-$0.55
Заводская прямая нажимная кабельная система управления
- Категория: Control Cables >>>
- Поставщик: Shanghai,Xinyuan,Wires,&,Cable,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.4 $* | 0.88 $* |
| Aug-16-2025 | 0.84 $* | 0.45 $* |
| Jul-16-2025 | 0.22 $* | 0.58 $* |
| Jun-16-2025 | 0.39 $* | 0.73 $* |
| May-16-2025 | 0.77 $* | 0.91 $* |
| Apr-16-2025 | 0.51 $* | 0.47 $* |
| Mar-16-2025 | 0.19 $* | 0.73 $* |
| Feb-16-2025 | 0.5 $* | 0.56 $* |
| Jan-16-2025 | 0.17 $* | 0.83 $* |
Характеристики
Product Description
Generally speaking, there are two ways of copper wires braided screen and copper tape wrapped screen for control cables, however, copper wires braided screen has stable structure, the effect of screen won’t change with the cable bending or appearance factors etc, but also doesn’t have influence on cables’ flexibility, braiding density can reach over 80%, besides,copper tape wrapped screen percentage of coverage can reach up to 100%.
Plastic PVC Insulated Screened control Cables are used for rated voltage up to and including 450/750V.
The long-term operating temperature of PVC insulation cable conductor should be lower than 70°C,and that of XLPE insulation should be lower than 90°C.
The installing ambient temperature of cables shouldn’t be lower than 0°C,the Min. bending radius of installing is 6 times of the outer diameter.
Unarmored control cables
Such unarmored control cables are suitable for laying indoors and in the electrical cabinets, however, the cables can’t bear larger external mechanical forces.
PVC sheath has stable property and excellent chemical corrosion protection characteristics, also with the features of non-fire propagation and non-water absorption, which greatly ensure the cables’ service life.
Control cables with steel wires armore
Steel wires armored control cables can endure certain mechanical tension, which are widely suitable for high-level difference environment, also can be installed vertically .Cables with screen have good shielding and anti-interference performances.
Model specification
Type | Name | Application Site |
KVV/KYJV | Copper conductor, PVC/XLPE insulation, PVC sheath control cable | For laying doors, in trenches and in ducts, for fixed installation. |
KYJ(F)V | Copper conductor, Irradiated cross-linked insulation, PVC sheath control cable | With flame retardant property and conductor Max. temperature of 90-150°C |
KVV22 KYJV22 | Copper conductor, PVC/XLPE insulation, PVC sheath control cable with steel tape armored | For laying doors, in ground, can withstand heavier mechanical force and for fixed installation. |
KYJ(F)V22 | Copper conductor, Irradiated cross-linked insulation, PVC sheath control cable with steel tape armored | With flame retardant property and conductor Max. temperature of 90-150°C, which can withstand heavier mechanical force |
KVVP KYJVP | Copper conductor, PVC/XLPE insulation, PVC sheath with copper wire braided shield control cable | For laying doors, in trenches and in ducts, such cable has the stable structure and excellent properties of anti-interference. |
KVVP2 KYJVP2 | Copper conductor, PVC/XLPE insulation, PVC sheath with copper tape wrapped shield control cable | For laying doors, in trenches and in ducts, the cable has stable structure and excellent properties of anti-interference also can withstand heavier mechanical force. |
KVVP22 KYJVP22 | Copper conductor, PVC/XLPE insulation, PVC sheath with copper wire braided shield and Steel tape armored control cable | For laying in doors, in ground and be able to withstand heavier mechanical force and good anti-interference properties for fixed installation. |
KVVP2-22 KYJVP2-22 | Copper conductor, PVC/XLPE insulation, PVC sheath with copper tape wrapped shield and Steel tape armored control cable | For laying in doors, in ground and be able to withstand heavier mechanical force and good anti-interference properties for fixed installation. |
KVV32 KYJV32 | Copper conductor, PVC/ XLPE insulation, PVC sheath control cable with steel wire armored | For laying doors, in ground, able to withstand heavier mechanical force and for fixed installation. |
KVVP32 KYJVP32 | Copper conductor, PVC/XLPE insulation, PVC sheath/ copper wires braided shield and steel wire armored control cable | For laying doors, in ground, able to withstand heavier mechanical force and for fixed installation. |
KVVP2-32 | Copper conductor, PVC insulation, PVC sheath with Copper tape wrapped shield and steel wire armored control cable | For laying doors, in ground, able to withstand heavier mechanical force and for fixed installation. |
KVVR | Copper conductor , PVC insulation and PVC sheath flexible control cable | For laying doors, connecting movable devices which can be used for movable installation. |
KVVRP | Copper conductor, PVC insulation and PVC sheath flexible control cable with copper wire braided shield | For laying doors with good property of shielding and anti-interference, for movable installation but can’t withstand external mechanical force. |
KVVRP2 | Copper conductor, PVC insulation and PVC sheath flexible control cable with copper tape wrapped shield | For laying doors with good property of shielding and anti-interference, for movable installation but can’t withstand external mechanical force. |
NH-KVV | Copper conductor, PVC insulation and PVC sheath fire-resistance control cable | Excellent property of flame-retardance and applies to high requirements of fire-fighting situation. |
Certificates
CCC, CE, ROHS ...
Certifications
Advantage
Packaging & Shipping
Packaging
Packing size: 100/roll, 200m/roll, 300m/roll, 305m/roll, 500m wooden reel, 1000m wooden reel
Packing material: PE Film, Wooden reel, plastic reel, and paper reel, Carton box or as request.
Shipping
1. 7-20 working days
2. Sea freight, Express(DHL,UPS,FEDEX, TNT),Train Way
Our Services
Our Services
1. Any inquiries will be replied within 24 hours.
2. OEM/ODM available.
1) Printing your logo on the cable.
2) Printing your logo on the pull box, wooden drum according to your design
3) Any your idea on cable, packing box are available.
3. High quality, reasonable and competitive price, fast lead time.
4. Good after-Sale Service.
1) All products will have been strictly Quality Checked in house before packing.
2) All products will be well packed before shipping.
5. Faster delivery.
Sample order in stock, and 3-7 days for bulk production.
6. Payment
We can accept payment methods: L/C, T/T, Western Union,other payment can negotiation.
Company Information
Shanghai Xinyuan Wire & Cable Co., Ltd, found in 2007, Two manufacturing plants in Shanghai and Hebei respectively, is a company professionally researching and producing low voltage power cable, medium voltage power cable, instrumentation cable, building wire, flexible rubber cable, fire rated cable, renewable cable, solar cable, industrial cable, coaxial cable etc. Annual production capacity is 200Thousand KM.
We have advanced and professional extrusion production lines and auxiliary inspection and test equipments, certified by ISO 9001:2015. The products are certified by CE, CCC, RoHS etc, providing measures and guarantee for product quality. the product is widely applied in the global scope in power distribution system, electrics, mechanism, lifting equipment and ship manufacturing, mining, construction, transportation, and other kinds of industrial, civil field.
Since the establishment of the company, we regard the market as the core, product oriented, technology - based, also take the quality as the lifeline, in order to vigorously promote the implementation of brand strategy for domestic and foreign markets. and consistently provide high quality wires and cables with competitive prices
Exhibitions
FAQ
1. Are we a trading company or manufacturer?
XY Cable is a genuine manufacturer, founded in 2007 with two manufacturing sites in China.
2. What can we supply?
We are focusing on low-voltage wire and cables, we can make most kinds of cables in this range.
3. When can you get prices?
We usually quote within 6 hours after we get your inquiry.
4. How can I get a sample to check the quality?
After price confirmation, a free sample is available, but the freight charge should be collected.
5. How long can I expect to get the sample?
After confirmed specs, the samples will be ready in 10 days and will be sent to you via express and arrive in 3~5 days.
6. OEM or ODM is available and if yes what is MOQ?
Yes, We offer OEM and ODM. We are good at design & produce cables according customers' idea. MOQ is 3km
7. What about the lead time for mass production?
Frankly, it depends on the order quantity and timing. It takes one week to produce 10KM as fast as we can. Generally speaking, we suggest you start orders two months ahead to get the products in time.
8. Besides email, what else channel can customers contact us?
You may contact via +86 13761119855 (WhatsApp and WeChat) or click My contact
