Трехфазный AC380V инверторов IGBT постоянного тока высокой частоты 100 процентов рабочий цикл оборудование для плазменной сварки автоматического
- Категория: Plasma Welders >>>
- Поставщик: Keyue,Welding,Equipment,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 1137.57 $* | 1160.60 $* |
| Jul-16-2025 | 922.37 $* | 940.35 $* |
| Jun-16-2025 | 1119.17 $* | 1141.71 $* |
| May-16-2025 | 1110.58 $* | 1132.59 $* |
| Apr-16-2025 | 886.51 $* | 904.29 $* |
| Mar-16-2025 | 1092.52 $* | 1114.96 $* |
| Feb-16-2025 | 1083.59 $* | 1105.76 $* |
| Jan-16-2025 | 1074.75 $* | 1095.46 $* |
Характеристики
Product description
Product feature
- Non-contact start with pilot arc
- Heavy duty: 60%
- Maximum cutting: 55mm
- Cutting type: manual and automatic(CNC)
- Material: mild steel, brass, stainless steel, copper, aluminum
| Model | CUT-160 |
| Input voltage(V) | 3PH AC380V±15% |
| Input power(KVA) | 29 |
| Input current (A) | 44 |
| Rated output | 144V/160A |
| Output current(A) | 40-160 |
| No-load voltage (V) | 380 |
| Duty Cycle% (40℃ 10min) | 160A 60% 124A 100% |
| Efficiency (%) | 80 |
| Protection grade | IP21 |
| Insulation grade | F |
| Method of arc start | un contact |
| Net weight (KG) | 56.8 |
| Gross weight (KG) | 69.6 |
| Dimension of machine (mm) | 700*355*635 |
| Dimension of package (mm) | 755*410*710 |
Performance
Material | Sheet thickness (mm) | Arc start | Current range(A) | Model |
Carbon steel, stainless steel, low alloy steel | 0.3-16.0 | Contact | 20-40A | CUT-40 |
| 1.0-25.0 | Contact | 20-60A | CUT-60 | |
| 1.0-30.0 | Uncontact | 20-100A | CUT-100 | |
| 1.0-35.0 | Uncontact | 20-120A | CUT-120 | |
| 1.0-40.0 | Uncontact | 20-160A | CUT-160 | |
| 1.0-50.0 | Uncontact | 20-200A | CUT-200 | |
| Copper, Copper alloy, Aluminum, Aluminum-alloy | 0.3-8.0 | Contact | 20-40A | CUT-40 |
| 1.0-13.0 | Contact | 20-60A | CUT-60 | |
| 1.0-15.0 | Uncontact | 20-100A | CUT-100 | |
| 1.0-18.0 | Uncontact | 20-120A | CUT-120 | |
| 1.0-20.0 | Uncontact | 20-160A | CUT-160 | |
| 1.0-25.0 | Uncontact | 20-200A | CUT-200 |
Accessories
Package
Company info
Workshop
Certificate
