Горизонтальный мини-компрессор boyard r134a 12 В для окружающей среды на

Описание и отзывы

Трекер стоимости

Характеристики

Rotary hermetic compressors use the rotating action of a roller inside a cylinder to compress the refrigerant.  Rotaries, by design, include less parts than other types of compression technology and provide an alternative, efficient option for various applications.
High efficiency BOYARD rotary compressors provide enhanced reliability, reduced sound and maximum flexibility with vertical and horizontal installation options for air conditioning and refrigeration applications.
Today’s modern air conditioning and commercial refrigeration applications require high efficiency combined with the ability to utilize more eco-friendly refrigerants. BOYARD rotary compressors continue to lead the way.



performance parameters:



Refrigerant		Power Supply	Model	Controller model	Cylinder Volume cm³	Speed Range	Rated Speed	Refrigerating Capacity		Input Power	COP	Height
						rpm	rpm	W	Btu/h	W		mm
VERTICAL	R134a	DC12V	JVB075Z12	BYC(D)12-400-4	7.5	2500-3700	3300	850	2890	340	2.50	228
		DC24V	JVB075Z24	BYC(D)24-400-4	7.5	2200-4500	3300	920	3128	340	2.70	228
			KVB135Z24	BYC(D)24-600-2	13.5	2500-4500	3300	1780	6052	580	3.07	269
		DC48V	JVB058Z48	BYC(D)48-300-4	5.8	2100-5400	3600	840	2856	255	3.30	190
			KVB135Z48	BYC(D)48-600-2	13.5	2500-4500	3300	1780	6052	560	3.17	269
			SVB208Z48	BYC(Z)48-1240-2	20.8	1500-4200	3600	3010	10234	970	3.10	271.5
		DC60-72V	JVB075Z72	BYC(D)72-400-4	7.5	2500-4500	3300	1020	3468	340	3.00	228
			KVB135Z72	BYC(J)72-600-3	13.5	2500-4500	3300	1780	6052	550	3.23	269
HORIZONTAL	R134a	DC12V	HB075Z12	BYC(D)12-400-4	7.5	2500-3700	3300	850	2890	340	2.50	136.5
		DC24V	HB075Z24	BYC(D)24-400-4	7.5	2500-4500	3300	920	3128	340	2.70	136.5
			JFB092Z24	BYC(D)24-400-4	9.2	2500-4500	3300	1100	3740	380	2.90	136.5
			JFB132Z24	BYC(D)24-700-4	13.2	2500-4500	3300	1710	5814	570	3.00	136.5
			KFB135Z24	BYC(D)24-600-2	13.5	2500-4500	3300	1780	6052	570	3.12	169
		DC48V	KFB135Z48	BYC(D)48-600-2	13.5	2500-4500	3300	1780	6052	570	3.17	169
			KFB208Z48	BYC(Z)48-1240-2	20.8	2500-4500	3600	2950	10030	900	3.27	169
			SFB208Z48	BYC(Z)48-1240-2	20.8	2500-4200	3600	3010	10234	970	3.10	150
		DC72V	HB075Z72	BYC(D)72-400-4	7.5	2500-5000	3300	1020	3468	340	3.00	136.5
			JFB092Z72	BYC(D)72-400-4	9.2	2500-5000	3300	1250	4250	380	3.30	136.5
			JFB132Z72	BYC(D)72-400-4	13.2	2500-5000	4300	2300	7820	700	3.25	136.5
			KFB135Z72	BYC(J)72-600-3	13.5	2500-4500	3300	1780	6052	550	3.23	169
			KFB135Z72	BYC(J)72-600-3	13.5	2500-4500	4300	2370	8058	720	3.30	169
			KFB164Z72	BYC(J)72-600-3	16.4	2500-4500	4300	2920	9928	860	3.40	169
			KFB208Z72	BYC(J)72-1000-3	20.8	2500-4500	3600	2950	10030	900	3.27	169
		DC312V	KFB208Z312	BYC(J)312-1000-3	20.8	2400-4500	3300	2950	10030	900	3.20	169
	R410A	DC220V	KFA102Z220	BYC(J)220-1000-3	10.2	2400-4500	4200	3675	12495	1150	3.20	160
		220V/50Hz	KFA113Z220	BYC(J)220-1000-3	11.3	2400-4500	3600	3450	11730	1080	3.20	160







Application:



RV-caravan air conditioner

excavator cab air conditioner

EV air conditioner

electric car air conditioner

motorhome air conditioner

Truck cab sleeper air conditioner

Solar air conditioner





sample service: could try sample firstly(Most models are in stock)
customized service: R&D as your requirement
After-sales service: With the technical support

Management system: ISO 9001
Production capacity: 20,000/Week
QC: CCC, CE, RoHS, REACH
Designed and developed: Have R&D Term
Export market: global (mainly for Europe, Middle East, America, SouthEast, etc.)
Exhibition Experience

1. Where is your company located in?
Located in Shuguang Road, Lanxi City, Zhejiang Province, China.



2. What's your delivery time?
25days for cargo; 5days for sample after payment or deposit.



3. What's your shipping port?
Ningbo or Shanghai Port.



4. What's your MOQ?
Could start as sample firstly, to match the application.



5. What's the payment terms?
T/T, L/C, ESCROW



6. How could do the payment?
T/T, ESCROW



7. What you supply?
- R22, R407C rotary air conditioner compressor
- R134a, R410a rotary compressor
- R134a DC 12V 24V 48V 72V compressor
- R22, R404a refrigeration compressor
- R22, R404a condensing unit
- R134a refrigerator compressor



8. Could you do the New products R&D service for me?
Any products of HVAC & refrigeration, we could do the R&D for you.
