Description



The GOOT® Phenolic Foam Pre-insulated Duct panel system the most advanced and nnovative energy saving system of air-distribution ductwork available worldwide. Ductwork is fabricated using rigid insulation panels in sections up to 3.95m-4m and can provide the optimum energy saving and environmental solution in comparison with other types of ductwork. The system consists of Phenolic Pre-insulated Duct Panels, fabrication methods, jointing systems and a complete line of accessories to produce a System where air leakage can be reduced to a fraction of that typical of sheet metal ductwork.







Advanges



Advantages compared to traditional insulated Sheet Metal Ductwork:

Do it in one time, no lag insulation required, save the labor and cost.

Save the buiding space

Very light, decrease the total weight of building

Little air leakage by flange joint connectting

Low thermal conductivity, no condensation and energy saving

Closed cell foam, good acoustic insulation

Fire proof, no smoke when exposing to fire

Faced with aluminum foil, it’s water proof and anti-microbial

CFC and HCFC free, environment friendly





Parameters





Item	Unit	Specification
Panel Structure		Alu./Foam/GI
Standard Panel Size	mm	3950*1200*20
Alu. Foil Thickness	mm	0.06
Galvanized/Alu.sheet/Painted Steel Sheet Thickness	mm	0.18
Foam Density	kg/m3	60
Thermal Conductivity	w/m.k	0.021
Compressing Strength	Mpa	0.25
Bending Strength	Mpa	1.2
Combustibility Property		Class 0 (BS476 Part 6 & 7) Class A (ASTM E84)
Water Absorption	%	1.9
Max Smoke Density	%	2
Dimension Change	%	0.3
Working Temperature	°C	-250- +150
Maximum Allowable Wind Velocity	m/s	≤15
Continuous Running Maximum Temperature	°C	≤120



Material Name	Phenolic Foam	Pu Foam	EPS Foam	Rock wool	Glass Magnesium Board
Density	Light	Light	Light	Heavy	Very heavy
Thermal Insulation	Perfect	Perfect	Normal	Bad	Worse
Water Absorption	Non-absorbent	Non-absorbent	Non-absorbent	Absorbent	Non-absorbent
Enviornmental protection	Degradable	Non-degradable	Non-degradable	Non-degradable	Non-degradable
	Non-toxic	Toxic when burning	Toxic when burning	Carcinogenic	Not enviornment friendly
Fire resistance	Fire resistant	Not fire resistant	Not fire resistant	Fire resistant	Fire resistant



From the table, we can see, phenolic resin has excellent heat insulation performance and excellent fireproof performance is excellent, environmental building materials.30mm thick phenolic insulation properties equivalent to 50mm rock wool board, 40mm polystyrene, 60mm glass magnesium, 800mm common brick insulation.
