combined peanut sheller & destoner machine

Peanut shelling machine has a compact and convenient, light weight, easy to move, easy to install, high efficiency, low cost, good cleaning effect and so on.
 Structure and working principle:
     Proper use of peanut shelling machine: peanut shelling machine has a rack, fan, rotor, single-phase motor, screen (with the size of two), into the hopper, vibrating screen, belt wheel and drive belt and so on.

After the normal operation of equipment, peanut quantitative, uniform, continuous input into the hopper, peanut under repeated attack, friction, collision of the rotor, peanut shells broken. Crushed peanuts and peanut shells and hit the rotor rotating under pressure, through a certain aperture sieve (peanut threshing first hole with a large screen, small leather fruit cleaning replaced after the first hole sieve the second shell), then, peanut shells, grain blowing force by rotation of the fan and light weight outer body is blown peanut shells, peanut screened by vibrating screen reach cleaning purposes.



 How it works: peanut by hand feeding, the first gate fell on rough paper, because of the paper plate is rotated and fixed-irons concave rubbing force between the plates, the peanut shells stripped after the separation of peanut shell while falling through the grid, then through the duct over by the wind will blow most of the peanut shell hit the machine, but not yet a part of peanuts and peanut peeling fruit together small proportion fall into the sorting screen, after re-screening, separating peanuts from the screen surface line, through feed entrance and exit into sacks, but have not yet peeled peanuts (small fruit), then the screen surface down, after crossing the material flow into the elevator, and then by the elevator into the fine lines and gate for the second shelling, and then after the election the proportion of branches screening , you can achieve all the peel.





pls feel free to contact me
