Распродажа мини-фрезерный станок с ЧПУ режущий для резки металлических заготовок Машина Для Резки Железа и Стали

Распродажа мини-фрезерный станок с ЧПУ режущий для резки металлических заготовок Машина Для Резки Железа и Стали

Категория: Metal Engraving Machinery >>>
Поставщик: Jinan,Senke,CNC,Machine,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-18-2025	0.99 $*	0.20 $*
Aug-18-2025	0.22 $*	0.23 $*
Jul-18-2025	0.95 $*	0.73 $*
Jun-18-2025	0.36 $*	0.31 $*
May-18-2025	0.93 $*	0.26 $*
Apr-18-2025	0.98 $*	0.13 $*
Mar-18-2025	0.21 $*	0.57 $*
Feb-18-2025	0.84 $*	0.95 $*
Jan-18-2025	0.22 $*	0.68 $*

Характеристики

hot sale mini cnc router machine cutting Metal Billet Cutting Machine for iron and steel engraving machine

Product Description

1. The machine whole cast iron body, chassis stability high load bearing, used for a long time never deformation, ensure the accuracy of metal processing requirements

2. Special metal spindle optional spindle has permanently power, long life, big power, the machining accuracy increase of 20%

3. Adopt imported ball screw, occlusive close, effectively meet the precision requirement of and improve the metal processing

4. taiwan square rails,support moving table,improving precision greatly,senke sample tested minimum forming 0.5 MM!

5. t-slot table,suitable for all kinds of materials, clamp help fixed carving materials

6. The machine with the sink, faucets and water pump matching accessories, can give the machine cooling in time, effective protection of the main shaft, the material, cutting tool

Technical parameter :

Model	SKM-3030	SKM-4040
XYZ axis working area	300300150mm	400400150mm
Machine Size	450x450*100mm
Machine frame	whole machine Cast iron
Spindle power	1.5KW/2.2kw/3kw special metal use spindle(water cooled)
XYZ movement	Ball Screw /Square rail
Max move speed	30000mm/min
Max engraving speed	5000mm/min
Spindle speed	0-24000rpm
Control system	NC-Studio as standard(DSP optional)
Drive Motors	servo motors&drivers(step motors optional)
Voltage	220v/380v or customized
Working Dictate	G -code
Software	artcam
Collet	ER20-32
Packing size	1.21.21.5M

Applications:

Advertising (metal plates, hot stamping plate), seals (chapters atoms, copper), signs, electronic, handicrafts, mold and decoration, can be for copper, aluminum, brass, iron, stainless steel, the atomic chapter, battery carbon plate, aluminum-plastic plate, Yang carved, Yin carving, line carve, tone, artistic relief, such as processing, support circular arc bottom, bottom tip, flat characters such as sculpture

machine parts
