 300 Ton cement silo for concrete mixing plant


Bolted cement silo, also known as cement tank and pills installed fission cement tank, suitable for storage of food, a variety of bulk materials such as cement, fly ash, mounted on the tank level system, can display the location of the material.Beijing bidragon bolted cement tank is cylindrical structure, by four circular tube at the bottom of the leg to support the whole tank, the tank are all steel structure, welding;At the top of the filter and pressure relief valve.The bolted cement tank containing steel structure part of tank, gym, guardrail, feeding tube, filter, pressure relief valve, high and low material level meter, discharge valve, etc., relative to the bulk cement tank, flake cement tank is mainly aimed at the traditional cement tank outlet tube packing problems, site system, site transfer difficulties, transport super great many problems, such as wide and thick bolted cement tank.Our company undertake a variety of tonnage flake cement tank, if you are interested in it, pls contact hotline: +8613213291534





Cement silo (cement tank) is suitable for engineering construction, commodity concrete mixing station, roads and Bridges of water conservancy projects, urban construction and other projects in the reserves of bulk cement silo.it has the waterproof, moistureproof, prevent loss of cement, reduce the dust pollution in the air in cities,  long service life and low cost etc. advantages.





Bolted cement tank features:
1. Cement tank is well-presented and sheet;
2. Bolted cement tank sealing performance is strong;
3. Bolted cement tank packing, transportation is convenient;
4. Bolted cement tank has realized the convenient installation and dismantling is convenient;
5. Effectively solves the export cement tank packing, on-site tube difficult, site transfer difficulties, transportation ultra high wide, and many other problems;
6. Storage silo is widely used in stored grain, cement, fly ash and other bulk materials, mounted on the tank level system, can display the location of the material;





Cement Silo Model



Silo model	Diameter	Height	Total height	with concrete batching plant model	with screw conveyor model
BD 30T	2.5m	4.8m	11.4m	JD350	LSY 163model
BD 50T	3m	5.4m	12m	JS500	LSY 180model
BD 80T	3m	9m	15.6m	JS750	LSY 180model
BD 100T	3m	11.4m	18m	JS1000	LSY 230model
BD 150T	3m	23.5m	29m	JS1000	LSY 230etc.
BD 200T	4.5m	18.6m	25.2m	JS1500	LSY 230etc.
BD 300T	4.5m	24.6m	29.5m	JS2000	LSY 230etc.
BD 500T	6M	22.2m	28.8m	JS3000	LSY230etc.
