PH8-800-155 балласт для GPH846T5HO GPH893T5HO GHO36T5L TUV36T5HO TUV55WHO TUV75WHO

Описание и отзывы

Трекер стоимости

Характеристики

PH8-800-155 ballast for GPH846T5HO GPH893T5HO GHO36T5L TUV36T5HO TUV55WHO TUV75WHO lamp

PH8-800-155 ballast for GPH1554T5HO GHO64T5L TUV64T5HO lamp

PH8 Series 99V to 264V universal voltage ballasts for 100W to 200W uv lamps

High power UV ballast with high lamp current 0.8A to 2.1A

Factory prices UV electronic ballast with all kinds of model and wattage.

All kinds of AC/DC Voltage

Suitable for most of UV lamps as below mentioned lists.

1.Suitable for UV lamps

PH8-800-155 UV Ballast

1xLamp types: GPH1554T5HO GHO64T5L TUV64T5HO

2xLamp types: GPH846T5HO GPH893T5HO GHO36T5 TUV36T5HO TUV55WHO TUV75WHO

PH8-1200-190  UV Ballast

1xLamp types: GPHA1000T5 GPHA1554T5

2xLamp types: GPHA843T5 GPHA357T5

PH8-1500-150 UV Ballast

1xLamp type: NNI120/79 NNI120/80 NNI120/84 NIQ120/80 NIQ120/84 TUV115WVHO

2xLamp type: NNI80/36U NIQ75/34 UVL80W/T5

PH8-1800-150 UV Ballast

1xLamp type: GPHA843T6 GPHA1000T6



2xLamp type: GPHA357T6



PH8-2100-200  UV Ballast

Lamp Type: GPHA1000T6

2.Technical specifications

Mains Voltage:110-240VAC±10%

Mains Frequency:50/60Hz

Power Factor: >0.98

Efficiency: >92%

Operating Frequency: 40-60KHz

Dimensions: 250*65*40mm

3.Lamp status forwarding

Potential free relay contacts for lamp on/lamp fault..

4.Installation requirement

Wire Gauge:0.5-1.0mm2

5.Mounting restrictions

Disconnect Input Power Before Installing or Servicing.

Ballast Case Must Be Grounded.

Don’t short any two wires of the four outputs.

6.Features

Starting:Preheat

7.Applications

All areas of applications includes UV lamps

Air purification

Industrial water treatment

Municipal water treatment
