2019 китайский поставщик буксированный вакуумный прицеп для сбора

What is the main Application of the Combi Truck and Characteristics?

1. With unique patent,the vehicle not only deal with grain dust includes micron&submicrn(remove fine grain dust under 1um),also for high temperature,high moist,poison grain dust and gas.Grain-remove effiency reaches 99%.

2. By application of theory of negative-pressure collection and positive pressure discharging.Multifunction Combination Suction&Discharging Vehicle is suction dry or wet material and discharging material into reclaimed warehouse or designated position.

3. The vehicle functions as material collection,transportation and  discharging,which has various advantage as resource saving,environment protection and lessen labor effort.

4.The vehicle not only can be applied for solid,powder or liquid material like cement,coal powder,lime powder,steel powder,etc wherever need,also for emergency case treatment,as collecting toxic material when environment pollution accident occurs.

Main Technical Parameter Show Blow:

3 grades shut off	Float ball	SS304
	solid material amount measurer
	ultrasonic liquid level indicator	Works as double float ball, cut off vacuum pump once tank is full
Powder filtration system	Bag filter	Filtration accuracy <1μm Max working temperature 260℃ Self cleaning with air cannon
	Cyclone dust separator	>5μm
	Inertial dust separator	>50μm
	Filter mesh (SS304)
Vacuum system	Brand	HIBON France
	Power source	Driven by PTO
	Vacuum level	-0.5bar
	Air flow	5700cu.m3/h
	Suction horizontal distance	≥50m
	Silencer
Discharge system	Butterfly valves

Inheritting near six decades of production experience, Huaian Xianglong Special Purpose Vehicle Co.,Ltd has been one of the advanced enterprises engaging in production of high-end municiple maintenance vehicles, emergency rescue vehicles, combination vacuum jetting trucks etc...

Our company is ISO 9001-2008 and sticks to Brand Managemen and commits to producing full series trucks covering: combination vacuum jetting truck, industrial wet and dry vacuum truck, power rescue vehicle, sludge dredging truck. The products have been widely sold in domestic and oversea market including Mideast, Australia, Africa, Southeast Asia…

Dozens of engineers and skilled workers have been trained in Belgium, Poland, Germany. By introducing European advanced design & production concept and continuously optimizing, now the company products meets international standard and leads domestic development trend.

What's our factory Professional advantage?

1. Use Split shaft PTO(Transfer case),which is common in Euro and America.Comparing to sandwish PTO used by other Chinese supplier,our method doesn't need to break down transmission box and don't change the transmission accuracy.

2.Jetting water pressure id pneumatically controlled.Avoid the sudden high pressure which may happen if you choose three-way value supplied by other Chinese factory.Our pneumatic safety valve is from Italy together with the water pump.

3.Use Liquid ring vacuum pump.Comparing to air cooling vane pump,air flow up to 2800m3/h,-0.95bar vacuum level and long continuous work time due to water cooling type.

4.Reverse discharge capability discharges water and leaves sludge,reduces round trip times between drainage well and dumping site.

5.Jetting nozzle works with linear high pressure water flow,makes the most effective use the water pressure.

6.Multiple safety protections,includ ultrasonic liquid level indicator,float ball,pressure safety value at the top of tank and vacuum air lines.

As municipal solution specialist,we factory always focus on Environment protection all around the world with high-end european quality and have already passed the safety approval as ISO9001,GS,SGS .Huaian XiangLong special purpose vehicle Co.,Ltd is a listing in Jiangsu Equity Exchange-stock Company,it's powerful symbols in China.

Our selling point is :Customization,High-end quality,Professional service,Innovation keep moving.
