4 канала комбайнер РФ пассивный

Описание и отзывы

Трекер стоимости

Характеристики

Specification	PORT1	PORT2	PORT3	PORT4
Frequency (Range( (MHz) (MHz)Range (MHz) (MHz) (MHz)	800~880	909~960	1710~1880	1920~2170
wideband (MHz)	80	51	170	250
Insertion loss (dB)	≤0.8
ripple in band (dB)	≤0.7
VSWR	≤1.25
out-of-Band rejection  (dB)	≥80@909~2170MHz	≥80 @800~880MHz ≥80@1710~2170MHz	≥80@1920~2170MHz ≥80@800~960MHz	≥80@800~1880MHz
Third-order intermodulation (dBc)	145@2×43dBm,160@2×43dBm
Max.powe (W)	300,1000
Working temperature	-25℃~+55℃
Working humidity	≤95%
Work pressure	86kPa~106kPa
Joint type	N-K
Dimensions(mm)	236mm×149mm×50mm





1.Packaging:paper box or wooden box;

2.Delivery time:usually within 7 days after payment;

3.Shipping ways:DHL/UPS/FEDEX/EMS etc;

4.Payment ways:T/T,Western Union,Paypal,Alibaba Trade Assurance.



1.Your inquiry related to our products or prices will be replied in 24 hours;

2.Well-trained and experienced staffs to answer all your inquiries in fluent English;

3.Monthly output over 2000pcs;

4.Strong package;

5. Sample order in small quantity is acceptable;





If you want to know more details,please contact us:
