  Energy-saving stabilization manufacturer force asphalt mix plants LDX 90











  Specifications







produce information





Technical index                                                                                                        LDX90



Nominal capacity                                                                                                      90t/h



Cold bin number                                                                                                          4



Plastic container volume                                                                                         6.5M ³



Standard burner                                                                                                   coal-fired



Rated fuel/coal                                                                                                     1000kg/h



Fuel oil/coal consumption rate (standard)                                                              12kg/t



Screening Series                                                                                                        4



Mixers mixing capacity rating                                                                                 1100kg/



Powder temporary warehousing capacity                                                                1.8M ³



New powder container volume                                                                                   --



Old powder container volume                                                                                    –



Under the finished container volume                                                                       35m ³



Asphalt tank                                                                                                         1x50 m ³



Heavy oil tank                                                                                                            –



Light tank                                                                                                                  –



Thermal oil heaters                                                                                                   –



Total power (standard)                                                                                     257.02kW



Overall dimensions                                                                                      37mx34mx20m

















main parts







Cold early with selection of chain plate type variable-frequency adjustable-speed mixing machine, rugged, accurate and reliable. Dryer skin stainless steel thermal insulation, four wheel drive, rear smoke box unique muffler design



Hot material chain hoist made of 40Cr, high tensile strength, long life; tensioning force parallel to the axle movement and anti-reversing devices, prevents the removal of chain and reduce failure rates



Dual-axis vibration inertial vibration Exciter on vibration source-vibrating, overcame the effects of high temperature on the vibrator, low rate of failure rate and the mixing cartridge, easy maintenance; turn the stopper is obtained a different size ranges of hot aggregate without the need to replace the screen, and failure of sieve plate replacement is simple and convenient





Blender twin-shaft dual-motor drive, mixing arm, mixed leaves, liners are made of high chromium wear-resistant materials, life of 100,000 batches and ARC discharge door design, overcoming mix blank corner







Structure of silo bottom-mounted storage of finished products, to meet different gradation of finished material storage and emergency waste disposal













package





company information



Haomei machinery equipment co.,Ltd is located in the famous machinery capital of Zhengzhou, China. We are professional machinery products manufacturer-featuring a wide range of quality asphalt mixing plant, concrete mixer, concrete batching plant, mobile concrete plant, concrete pump, truck pump with boom, truck mixer, etc. We adhere to the policy of "QUALITY FIRST AND INTEGRITY WINS" to cooperate with clients from all over the world. Our company covers over 100 acres with workshop area of more than 50,000 square meters has 5 branches.
