  Dry Type Domestic Cold Single Jet  Water Meter

• Product Description:

1. Item: Dry Type Domestic Cold Single Jet  Water Meter
2.  Material: brass meter body
3.  Size:15mm ~25mm(LXSC-13D ~25D)
4. Standard: ISO4064 Class B, dry type , pulse output avaliabe.

• APPLICATION:
• Measuring the volume of cold potable water passing through the pipeline.
• FEATURES:

1.  Single jet, dry dial;
2.   Dry type .small, light, magnetic drive ,free rotating register, easy and long term clear reading etc. Magnet resistance
3.  Optimum accuracy and performance at all times;
4.  Accurate measurement, easy and long term clear reading, etc.
5.  Measuring accuracy is up to ISO4064, Class B (EN  14154  & MID  2004/22/EC  European  standard  and  OIML- R49  standard on request)

• WORKING CONDITION:

1. Water temperature: Cold Water Meter ≤40℃ Hot Water Meter ≤90℃
2. Water pressure: ≤1.6Mpa (16bar)



• MAXIMUM PERMISSIBLE ERROR:

1. In the lower zone from q min inclusive up to but excluding qt is ±5%
2. In the upper zone from qt inclusive up to and including qs is ±2%











The single-jet water meter is mainly used as a divisional counter in the households. It’s simple design makes it a product with a competitive price and highly reliable operation. The principle of operation is given by the incidence of a single tangential stream of water with a turbine mounted in a radial position within the body of the meter. The rotation of the turbine transmits the motion to the reading mechanism allowing the measurement of the volume of water passing through the meter. The rotation speed of the turbine is proportional to the water flow in inlet and any variation in the relationship between the characteristics of the turbine and the water flow would entail an alteration of the error curve of the meter. There are three single-jet water meter types:
- Wet dial meters with the reading mechanism completely immersed in the water and direct transmission from the turbine to the gears of the mechanism itself.
- Semi dry dial meter with the reading mechanism completely immersed in the water and the rollers protected in a sealed capsule. Direct transmission from the turbine to the gears of the reading mechanism.
- Dry dial meter with the reading mechanism completely separate from the hydraulic chamber by a watertight plate. In this case the transmission from the turbine to the reading mechanism gears takes place via magnetic coupling.

45 degree register, brass meter body, ISO4064 Class B, dry type , pulse output avaliabe
