Китайско Galvo высокой скорости 10 мм УФ-CO2 сканер лазерного гальванометра маркирующая головка для лазерная маркировочная
- Категория: Лазерное оборудование для промышленности >>>
- Поставщик: Sino-Galvo,(beijing),Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 0.60 $* | 0.27 $* |
| Aug-17-2025 | 0.98 $* | 0.40 $* |
| Jul-17-2025 | 0.96 $* | 0.80 $* |
| Jun-17-2025 | 0.31 $* | 0.74 $* |
| May-17-2025 | 0.12 $* | 0.70 $* |
| Apr-17-2025 | 0.59 $* | 0.34 $* |
| Mar-17-2025 | 0.36 $* | 0.2 $* |
| Feb-17-2025 | 0.66 $* | 0.49 $* |
| Jan-17-2025 | 0.47 $* | 0.84 $* |
Характеристики
Products Description
Product Parameters
Speed | ||||
Marking Speed(1) | 6500mm/s | |||
Writing Speed(2) | 530cps | |||
Step Response Time(1% of full scale) | 280us | |||
Step Response Time(10% of full scale) | 890us | |||
Tracking Error Time | ≤160us | |||
Precision and Error | ||||
Linearity | 99.9% | |||
Repeatability (RMS) | ＜8μRad | |||
Gain Error | ＜5mRad | |||
Zero Offset | ＜5mRad | |||
Long-term Drift Over 8 Hours | ＜0.5mRad | |||
Scale Drift | ＜40PPM/℃ | |||
Zero Drift | ＜15μRad/℃ | |||
Wavelength(3) | 10600nm/1064nm/355nm | |||
Power and Signal | ||||
Input Voltage | ±15VDC | |||
Rated Current | 2A | |||
Interface Signal | Digital | XY2-100 | ||
Analog | ±5V | |||
Max Machinery Scan Angle(4) | ±15° | |||
Working Current, Temperature, Dimension | ||||
Working Temperature | 0℃--45℃ | |||
Storage Temperature | -10℃--60℃ | |||
Aperture | 10mm | |||
Galvanometer Scanner Dimension (LxWxH) | 118.5x96.5x94mm | |||
Galvanometer Scanner Weight | ≈1.65Kg | |||
