Характеристики
PCB Manufacturer in China and High Quality PCB Board Manufacturer with PCB Assembly Service
Thanks for choosing Fumax
- Your Best Reliable Design & Manufacturing Partner in China!
Fumax can provide excellent Turnkey project service for worldwide customers. Our factory has over 800 staff with a group of experienced mechanical & Electronic engineers. We are able to manufacture products starting from initial product design, Electronic Circuit Design, PCB Layout, Components Sourcing & Purchasing, Plastic / Metal mechanical design, Mold / Tooling design & fabrication, sub-assembly, full assebmly to final product testing / package.
Product Description
PCB Manufacturer in China and High Quality PCB Board Manufacturer with PCB Assembly Service
Products Application:
-Household appliance
-Medical products
-Automotive products
-Industrial products
-Consumer electronics
PCB Technical Capabilities:
Layer | 1-32 layers |
Material | FR4,CEM1,CEM3,Hight TG,FR4 Halogen Free,FR1,FR2,94v0 |
Order Quantity | 1-500,000 |
Board shape | Rectangular,round,slots,cutouts,complex,irregular |
Board type | Rigid,flexible,rigid-flexible |
Board material | FR-4,glass epoxy,FR4 High Tg,Rohs compliant,Aluminum,Rogers,etc |
Board cutting | Shear,V-score,tab-routed |
Board thickness | 0.2~4.0mm,Flex 0.01~0.25'' |
Copper weight | 1.0,1.5,2.0oz |
Solder mask | Double-sided green LPI,Also support red,white,yellow,blue,black |
Silk screen | Double-sided or single-sided in white,yellow,black,or negative |
Silk screen min line width | 0.006'' or 0.15mm |
Max board dimensions | 20inch*20inch or 500mm*500mm |
Min drill hole diameter | 0.01'',0.25mm.or 10 mils |
Surface finish | HASL,Nickle,Imm Gold(ENIG),Imm Tin,Imm Silver,OSP etc |
Board thickness tolerance | ± 10% |
Copper weight tolerance | ± 0.25oz |
Minimal slot width | 0.12'',3.0mm,or 120mils |
V-score depth | 20-25% of board thickness |
Plated through holes | Yes |
Sink holes | Yes |
Design file format | Gerber RS-274X,274D,Eagle and AutoCAD'S DXF,DWG |
PCB Assembly SMT & DIP manufacturing Capabilities:
Quantity | Prototype, Low, Medium, High Volume PCB Assembly, |
Type of Assembly | SMT, Thru-hole, Cable assembly, Wire Harness |
Min. IC Pitch | 0.30mm |
Foot Pin | SO, SOP, SOJ, TSOP, TSSOP, QFP, BGA and U-BGA |
Min. Chip Placement | 1005 |
Max. PCB Size | 410 x 600mm |
Min. PCB Thickness | 0.35mm |
Maximum BGA Size | 74 x 74mm |
BGA Ball Pitch | 1mm ~ 3mm |
BGA Ball Diameter | 0.4mm ~ 1mm |
QFP Lead Pitch | 0.38mm ~ 2.54mm |
Solder Type | Water Soluble Solder, Lead-Free, Wave soldering |
Components | Passive Down to 0201 size |
BGA and VFBGA | |
Leadless Chip Carriers/CSP/QFN | |
Double-sided SMT Assembly | |
Fine Pitch to 0.8mils | |
BGA Repair and Reball | |
Part Removal and Replacement | |
File Format | Bill of Materials |
Gerber files | |
Pick-N-Place file | |
Types of Service | Turn-key, Partial turn-key or consignment, pilot run |
Component packaging | Cut Tape, Tube ,Reels, Loose Parts |
Turn Time | Same day service to 15 days service |
Programing | Hex file or bin file firmware. |
Testing | Flying Probe Test, X-ray Inspection AOI Test |
Package | Anti-static Bubble Bag & Carton |
PCB assembly process | IQC for incoming materials checking----Material baking----SMT----- Semi-Products Testing & QC ---DIP parts -- IPQC--- Wave Soldering--Semi-Products Testing & QC-----Assembling-----ICT or X-ray-----100% Function Testing-----Reliability Testing (burn-testing) - Package - Shipping |
Finished Assembly:
Make you a finished product - Turnkey Project - Directly shipping to your customers! | ||
Finished Assembly | PCB Assembly + Plastic Enclosure | + Package |
PCB Assembly + Metal Enclosure | + Package | |
PCB Assebmly + Cable | + Package | |
PCB Assebmly + Wire Harness | + Package | |
PCB Assebmly + any combined or other enclosures | + Package | |
Company Information
Fumax - Your Best Reliable Design & Manufacturing Partner in China!
Our dedication to cutting-edge technology, product excellence, consistent quality, competitive pricing, unsurpassed service and customer satisfaction has brought us outstanding recognition in these industries.
Our OEM/ODM design team has the expertise to rapidly prototype upon the approval of finalized specifications. In addition, the winning of ISO-9001 certification ensures the exactitude of our research and development procedures with the highest product quality. For complete customer satisfaction, we also provide an extended product service and warranty program.
Our current products line included, but not limited to:
Consumer Electronics | Video player, Audio products, Cafe Machine |
Industrial control | Motor Control board, Industrial Control, Machine Board…etc. |
Wireless industry | Smart Card Readers, Wireless communication |
Tele-communication | Communication Modules |
Medical | electrocardiograph monitoring, Blood Press Meter |
Plastic/Metals | Metal Emblems, Stapler, Calculators, Screw Driver, Hammer |
And many other OEM/ODM products | |
Strong Sourcing &Supplier Chain Management:
Factory View:
Our Services
(1) Fumax employs a complete team of engineers from a variety of backgrounds :
- Industry Designers
- Electronic Engineers
- Mechanical/Construction Engineers
- Mold/Tool Engineers
- Package Engineers
(2) OEM (We manufacture according to your design - BOM, Gerber file and testing procedures, while providing you best recommendations for easy manufacturing and cost saving):
- Component sourcing and procurement
- PCB Manufacturing
- Component Assembly (PCBA–SMT & Through Hole parts)
Chip-on-board (COB)
Surface-mount technology (SMT)
Ball-grid array (BGA)
Through-hole
- Plastic Enclosure (Mould) Manufacturing
- Metal Enclosure (Tool) Manufacturing
- Cable & Wire harness Assembly
- Final Assembly
- QC Testing
- Packaging
(3) ODM (We design and manufacture for you):
- New Product Design
- PCB Layout
- Reverse Engineering
- Software Programming
FAQ
(1)Why working with Fumax?
- Sign NDA (Non-disclouser Agreement) for All customers
- Protect customer's copy right
- Small- to medium-volume are welcome
- Purchase all components based on client BOM list
- One-stop turnkey solution
(2) What you need to provide for OEM quote?
- BOM (Bill of Materials) & Gerber files
-To short the lead time, please kindly advise us if there is any acceptable components substitution.
ŸTesting Method
- Software if need programming
For ODM
- Detail function requirements of the project you want to development.
- Board size /layers requirement
