75 Вт 24В 3.2A Meanwell EDR-75-24 Smps трансформатор din-рейка один выход 2 года
- Категория: Switching Power Supply >>>
- Поставщик: Hangzhou,Jiang,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.56 $* | 0.89 $* |
| Aug-18-2025 | 0.61 $* | 0.25 $* |
| Jul-18-2025 | 0.65 $* | 0.43 $* |
| Jun-18-2025 | 0.83 $* | 0.51 $* |
| May-18-2025 | 0.28 $* | 0.10 $* |
| Apr-18-2025 | 0.45 $* | 0.24 $* |
| Mar-18-2025 | 0.58 $* | 0.25 $* |
| Feb-18-2025 | 0.16 $* | 0.27 $* |
| Jan-18-2025 | 0.86 $* | 0.91 $* |
Характеристики
75W 24V 3.2A Meanwell EDR-75-24 Smps Transformer DIN Rail Single Output 2 Years Warranty
Product Overviews
Features:
- Meanwell Smps Transformer
- Universal AC input/Full range
- Protections: Short circuit / Overload / Over voltage/Overtemperature
- Cooling by free air convection
- Can be installed on DIN rail TS-35 / 7.5 or 15
- UL508 (industrial control equipment) approved
- EN61000-6-2(EN50082-2) industrial immunity level
- 100% full load burn-in test
- 2 years warranty
Application:
- Industrial control system
- Semiconductor fabrication equipment
- Factory automation
- Electro-mechanical apparatus
Details:
| MODEL NO. | EDR-75-24 |
| AC INPUT VOLTAGE RANGE | 90 ~ 264VAC 127 ~ 370VDC |
| DC OUTPUT VOLTAGE | 24V |
| CURRENT RANGE | 0 ~ 3.2A |
| RATED POWER | 76.8W |
| DC VOLTAGE ADJ. RANGE | 24~28V |
| INRUSH CURRENT | Cold Start, 35A at 230VAC |
| OVERLOAD | 105 ~ 130% Constant current limiting, auto-recovery |
| OVER VOLTAGE | 29 ~ 33V |
| OVER TEMPERATURE | Shut down o/p voltage, re-power on to recover |
| WORKING TEMP. | -20 +60°C |
| SAFETY STANDARDS | Ul508, TUV EN60950-1 approved |
| DIMENSION | 32*125.2*102mm (W*H*D) |
| PACKING | 0.51Kg; 28pcs/15.3Kg/1.22CUFT |
