THR-LT002 Высокое качество ультразвуковой Сканнер цифрового

Specifications:

Dispaly

15 inches high-resolution LCD

Scanning Mode

Electronic convex array, Electronic linear array

Display Mode

B, B/B, B/M and M

Magnification

x0.8, x1.0, x1.2, x1.3, x1.5, x1.6, x1.8, x2.0

Gray Scale

256

Resolution

Horizontal≤2mm, Vertical ≤1mm

Geometrical Precision

≤5%

Blind Area

≤3mm

TGC

8-section TGC adjustment

Pseudo Colors

Yes

Display Depth

240mm and depth could be increased

Image Polarity

Left/right, positive/negative and up/down

Cineloop

Successive 256 frames

Output Interface

Three output interfaces:1 VGA and 2 PAL video signal output

Power Supply Range

AC 110V60Hz, 220V50Hz

Leading Digital Technologies

Advantages

DBF: Digital Beam Forming

RDF: Real-time Dynamic Filtering

DFS: Dynamic Frequency Scanning

RDA: Real-time Dynamic Aperture

THI Frequency

Histogram

Double connectors

Double USB ports

LCD display

Image Processing

Software Functions

2D images, can be improved into 3D too.

The functions of frame correlation,

8 kinds of Υ Adjustments, edge enhancement held,

as well as the functions of pretreatment,

post processing, THI Frequency,

left-right reversing and up-down reversing Image displaying ratio: magnification, can be increased.

Local zooming functions held

Digital Beam Forming, Histogram

General measurement:

distance, circumference, area, oval, trace,volume, HR, gestational week

Obstetric measurement soft:

GS, CRL, BPD, AC, HC, FL, AFI, EDD, and calculating fetus weight, pregnancy week, expected delivery date,

fetal physiological rating according to the previous measurements

Features

Configuration Available

Laptop design

15 inches high-resolution LCD

8 TGC controls

High-quality images

Broadband multi-frequency transducers

Cineloop

Two USB ports

Two connectors

Pseudo Colors

Main unit

15 inches high-resolution LCD

256-frame cineloop

3.5MHz electronic convex transducer

5.0Mhz micro-covex transducer

Electronic transvaginal transducer

Electronic high-frequency linear trandducer

3D image software

Trolley, Video Printer
