XY-3 буровая установка для воды бурения


Поделиться:


Цена:*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-18-2025 0.43 $* 0.94 $*
Aug-18-2025 0.42 $* 0.43 $*
Jul-18-2025 0.12 $* 0.47 $*
Jun-18-2025 0.7 $* 0.75 $*
May-18-2025 0.99 $* 0.57 $*
Apr-18-2025 0.89 $* 0.29 $*
Mar-18-2025 0.98 $* 0.67 $*
Feb-18-2025 0.17 $* 0.41 $*
Jan-18-2025 0.65 $* 0.0 $*

Характеристики


                             XY-3 drilling rig machine for water, drilling rig water well



XY-3 directional drilling rig from our drilling rig factory is mainly used for geological explorationhydropower projectroad and railway constructionbuliding project and big diameter water well project








a. XY-3 drilling rig adopts CG140 model auto transmission, has 10 rotation speeds and easonable speed range, with eight forward roation gears and two reverse rotation gears, high speed, strong stroke and wide scope of application.

b. Large engine power and two reverse rotation gears, can easily solve the drilling work accident.

c. The operation handles are fixed together in reasonable layout to make it more convenient for workers to operate the machine.

d. Equipped with normally closed hydraulic chuck, operation is flexible and reliable

e. Spindle and hoist can be operated separately.

f.  Spindle has big inner diameter, able to use big hexagonal drilling rod.






Unity machine parameter
Drilling depth600m
Max open hole caliber300mm
End hole caliber75mm
Drilling Rod diameter60mm
Drilling angle90°~65°
Dimension2500 x 900 x 1800mm
Drill weight (without power)1600kg
Spindle
spindle speedForward 30-1050r/min
Reverse 29 137r/min
Spindle stroke600mm
Spindle inner diameter96mm
Lifting capacity6000kg
Hoist
Max.Single line lifting capacity4000kg
Max.Single line lifting speed0.5-1.9m/s
Wirerope caliber12.5mm
Wirerope length50m
Reel diameter300mm
Hug folldgate belt width90mm
Mud pump
TypeBW-250
Displacement250 L/min
Work pressure80kg/cm²
Water inlet pipe diameter75 mm
Water outlet pipe diameter50 mm
Gear Oil pump
Duplex gear oil pumpCBF-F63/25
Front Displacement, pressure63 L/min  20Mpa
Behind Displacement, pressure25 L/min  20Mpa
Power
Diesel engine4105 76HP
Electric motorY180L-4 59KW








Package: Plastic sheeting

Delivery: Container ship, 10 days after receiving deposit














1,Are you trading company or manufacturer?
We are absolutely professional manufacturer, and our factory mainly produce water well drilling rig, core drilling rig, piling rig, etc. We provide comprehensive solution to many fields like geological survey, mining industry, electric power etc.

Our products have been exported to more than 50 countries of Asia, South America, Africa, and get a good reputation in the world.

2,Are your products qualified?

Yes, our products all have gained ISO certificate, and we have specialized quality inspection department for checking every machine before leaving our factory.

3,How about your machine quality?
All of our machines hold the  ISO, QC certificate, and each set of machine must pass a great number of strict testing in order to offer the best quality to our customers.

4,Do you have after service?
Yes, we have special service team which will offer you professional guidance. If you need, we can send our engineer to your worksite and provid the training for your staff.

5,What about the qaulity warranty?
We offer one-year quality warranty for machines' main body.

6,How long can you deliver the machine?
Generally, we can deliver the machine in 10 days.
