5 Вт UHF 400-520 МГц иди и болтай Walkie Talkie “иди KD-C1 WLN 2 Way Радио Мини Ham
- Категория: Портативная рация >>>
- Поставщик: Shenzhen,Anysecu,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-15-2025 | 9.91 $* | 9.19 $* |
| Jul-15-2025 | 7.93 $* | 7.3 $* |
| Jun-15-2025 | 9.56 $* | 9.39 $* |
| May-15-2025 | 9.95 $* | 9.73 $* |
| Apr-15-2025 | 7.60 $* | 7.67 $* |
| Mar-15-2025 | 9.16 $* | 9.37 $* |
| Feb-15-2025 | 8.91 $* | 8.56 $* |
| Jan-15-2025 | 8.5 $* | 8.44 $* |
Характеристики
5W UHF 400-520MHz Walkie Talkie KD-C1 WLN 2 Way Radios Mini Ham Radio
Product Description
Features:
* 50 CTCSS/105 CDCSS.
* VOX Function.
* Voice Prompt.
* PC Programming.
* Emergency Alarm.
* Intelligent Charging.
* Battery Save.
* Low Voltage Alert.
* Time-out Timer.
* Specification :
* General Frequency Range:400-470MHz
* Operation Voltage:DC3.7V
* Channel Capacity:16
* Antenna Integrated antenna
* Antenna Impedance:50
* Dimension:96x55x22mm
* Transmit Output power:3W
* The maximum deviation:≤±5KHz
* Residual radiation:<60dB
* Current:≤1000mA
* Receiver Sensitivity:<0.16μV(12dB SINAD
* Squelch Sensitivity:<0.2μV
* Intermodulation:50dB
* Audio Power:≥300mW
* current:≤100mA
* Squelch current: 20mA
* VOX Function.
* Voice Prompt.
* PC Programming.
* Emergency Alarm.
* Intelligent Charging.
* Battery Save.
* Low Voltage Alert.
* Time-out Timer.
* Specification :
* General Frequency Range:400-470MHz
* Operation Voltage:DC3.7V
* Channel Capacity:16
* Antenna Integrated antenna
* Antenna Impedance:50
* Dimension:96x55x22mm
* Transmit Output power:3W
* The maximum deviation:≤±5KHz
* Residual radiation:<60dB
* Current:≤1000mA
* Receiver Sensitivity:<0.16μV(12dB SINAD
* Squelch Sensitivity:<0.2μV
* Intermodulation:50dB
* Audio Power:≥300mW
* current:≤100mA
* Squelch current: 20mA
Specifications: | |
Model | WLN KD-C1 |
Frequency | UHF 400-470MHz |
Channels | 16 channels |
Channel Spacing | 25KHz |
Operated Voltage | 3.7 V |
Battery | 1500MAh Li-ion |
Battery Life(5-5-90 duty cycle) | About 8 hours |
Frequency Stability | ±2.5ppm |
Operated Temperature | -30°c-+60°c |
Antenna Impedance | 50Ω |
Dimensions (L×W×H) (with battery,without antenna) | 110×50×32 mm |
Weight (with battery/antenna) | 198g |
Communication Range | about 6km |
Transmitter | |
RF Power Output | <5W |
Spurious Emission | ≤65dB |
Modulation | F3E |
FM Noise | ≤-45dB(W) ≤-40dB (N) |
Audio Distortion | ≤5% |
Transmitting Current | ≤1.3A |
Receiver | |
Sensitivity (12dB SINAD) | ≤0.20 uV |
Selectivity | 55dB/50dB |
Intermodulation | ≥65dB |
Adjacent Channel Selectivity | ≥60dB |
Spurious Response | ≥60dB |
FM Noise | 45dB/40dB |
Audio Power Output | 1000mW |
Audio Distortion | ≤5% |
Standby Current | ≈15mA (with battery save on) |
