Транспортировочное оборудование 5 тонн электрическая тележка для транспортировки на платформе
- Категория: Специальный транспорт >>>
- Поставщик: HENGN,HENGTAI,HEAVY,INDUSTRY,GROUP,CO.,LTD
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.54 $* | 0.13 $* |
| Aug-20-2025 | 0.18 $* | 0.97 $* |
| Jul-20-2025 | 0.6 $* | 0.0 $* |
| Jun-20-2025 | 0.78 $* | 0.32 $* |
| May-20-2025 | 0.92 $* | 0.97 $* |
| Apr-20-2025 | 0.51 $* | 0.73 $* |
| Mar-20-2025 | 0.84 $* | 0.11 $* |
| Feb-20-2025 | 0.65 $* | 0.96 $* |
| Jan-20-2025 | 0.16 $* | 0.83 $* |
Характеристики
Carrying equipment 5 ton electric flat car, electric flat carriage for sale
Product Description
1. Specifications of electric flat carriage
1.Steel box beam structure
2.Applied in anti-explosive environment
3.Convenient and efficient
4.ISO/CE/CCC
2. Application:
electric flat carriage are used: to carry loads along assembly lines; transfer material from one work station to the next; store and transport an entire shift worth of production. They can even be used as a stable yet moveable machine base.
3. Different Types:
KPT type is powered by the cable laid on the ground directly. For its simple structure, the price is more competitive. While the distance is often limited in 100 meter
KPJ type is powered by the cable from the cable reel. With the cable reel, the moving distance is improved to 200 meter compared with the KPT type.
KPX type is powered by the storage battery. Without the cable,this kind of transfer cart is more flexible and safe. While the capacity and the duty group are all affected by the storage battery. Especially,the price and the life span of the bettery is also an important issure.
KPC type is powered by the slide wire along the rail, so the moving distance is unlimited. The slide wire is the key point and also the weakest link.
KPD/PKDZ type is powered by the low voltage DC power from the rail. Powered by the rail, the system is more reliable compared with the KPC type;the sytem is also more complicated and expensive.
4.Technical Parameters of electric flat carriage
Model | KPDZ-2T | KPDZ-5T | KPDZ-10T | KPDZ-16T | KPDZ-20T | KPDZ-25T | KPDZ-30T | KPDZ-40T | KPDZ-50T | KPDZ-63T | |
Rated Load(t) | 2 | 5 | 10 | 16 | 20 | 25 | 30 | 40 | 50 | 63 | |
Table Size (mm) | Length (L) | 2000 | 3500 | 3600 | 4000 | 4000 | 4500 | 4500 | 5000 | 5500 | 5600 |
Width (W) | 1500 | 2000 | 2000 | 2000 | 2200 | 2200 | 2200 | 2500 | 2500 | 2500 | |
Height (H) | 450 | 450 | 500 | 500 | 600 | 600 | 600 | 650 | 650 | 750 | |
Wheel Base(mm) | 1200 | 2500 | 2600 | 2800 | 3200 | 3200 | 3200 | 4200 | 4200 | 4300 | |
Rail Inner Gauge (mm) | 1200 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | 1435 | |
Wheel Diameter(mm) | Φ270 | Φ300 | Φ300 | Φ350 | Φ400 | Φ400 | Φ400 | Φ500 | Φ500 | Φ600 | |
Wheel Quantity | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | |
Ground Clearance(mm) | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 75 | |
Running Speed(min) | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | 0-20 | |
Motor Power(KW) | 1 | 1.2 | 1.6 | 2 | 2.2 | 3 | 3.5 | 4 | 5 | 6.3 | |
Transformer Quantity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 | |
Running Distance(m) | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 60 | 50 | 50 | |
Max Wheel Load(KN) | 14.4 | 25.8 | 42.6 | 64.5 | 77.5 | 94.5 | 110.5 | 142.5 | 174 | 221.4 | |
Reference Weight(t) | 2.8 | 3.6 | 4.2 | 5.5 | 5.9 | 6.5 | 6.8 | 7.6 | 8 | 10.8 | |
Recommended Rail Model | P15 | P18 | P18 | P24 | P24 | P38 | P38 | P43 | P43 | P50 | |
Packaging & Shipping
electric flat carriage
Packaging Detail:Standard type with electric flat carriage
Delivery Detail:Within 20 working days after depoist received
Our Services
electric flat carriage
Delievery Time: After signing the contract and recieving the depoist, the production will take 15~25 working days. Special standard make cost 5~10 more working days.
Order Tracking: After the depoist recieved, there will be a professional team tracking the order from production to package and shipment.
Crane Testing: All the materials are purchased from high quality supplier in China or the world, beyond this, we also make commissioning and test before packagement to avoid the trouble back.
Company Information
electric flat carriage
♥ Henan Hengtai Hoisting equipment Co., Ltd. have rich experience on Design, Develop, Manufacture and Export industry Lift Equipment. We know every details about the Crane Application in Every Industries. Here in China, We are top of line!
♥ We have exported our industy cranes to over many countries, such as Europe, America, Japan, Southeast Asia and other countries and regions. and received good feedback from them.
♥ Our Crane is serving Tube making industry, auto industry, Rialway construction, Cement industry, Steel, coal mine, Power, Port, Chemical and other heavy Industry.
FAQ
electric flat carriage
1. Q: Are you a trading company or a factory?
A: We are factory which has a lot of experience.
2. Q: Do you accept special design?
A: Yes, we can design and manufacture products according to client's special requirements
3. Q: What about your package?
4. Q: How long will you take before shipping?
A: It is according to the products you need.
