Астрономический и годовой
- Категория: Time Switches >>>
- Поставщик: Yueqing,Jinghan,Electronic,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.55 $* | 0.76 $* |
| Aug-19-2025 | 0.95 $* | 0.10 $* |
| Jul-19-2025 | 0.83 $* | 0.88 $* |
| Jun-19-2025 | 0.73 $* | 0.88 $* |
| May-19-2025 | 0.36 $* | 0.91 $* |
| Apr-19-2025 | 0.72 $* | 0.13 $* |
| Mar-19-2025 | 0.63 $* | 0.44 $* |
| Feb-19-2025 | 0.61 $* | 0.60 $* |
| Jan-19-2025 | 0.38 $* | 0.64 $* |
Характеристики
Product Description
Features
1. Digital time switch with yearly and astro programs;
2. 10 years power reserve(lituium battery)
3. 80 programs
4. Sealable cover of the front panel, easy setting by 4 keys
5. Automatic summer/winter time changeover
6. LCD display with backlight
7. Holiday mode
8. Single channel
9. Manual contro by keys combination
10. Automatic transfer of weekdays
11. 24-264Vac/dc input supply
12. Double module, mounted on TH-35 rail.
Product description
| Model | DT1-M2 | |
| Supply terminals | A1-A2 | |
| Rated voltage | AC/DC 24-264V ±10% | |
| Rated frequency | 50/60Hz | |
| Power consumption | 2W | |
| Number of programs | 80 | |
| Program | Weekly program, yearly, astronomical | |
| Mode of work | Manual,automatic, holiday, random | |
| Summer/winter time | Off, automatic transfer | |
| Time tolerance | ≤1s/day at 25℃ | |
| Power reserve | 10 year | |
| Data readout | Backlighted LCD display | |
| Number of contacts | 2 C/O | |
| Current of contacts | 16A/250V AC1 | |
| Switching capacity | 4000VA/AC1,384W/DC | |
| Mechanical life | 10000000 | |
| Electrical life | 1000000 | |
| Protection degree | IP20 | |
| Pollution degree | 3 | |
| Altitude | ≤2000m | |
| Mounting | TH-35 Rail | |
| Standard | EN60730-1/EN60730-2-7 | |
