Обувной штамп/Пресс-гравировальный станок/металлический фрезерный

.

1. Using casting iron bed seat, gantry framework, fixed beam layout.

2. X,Y,Z axis, Taiwan original guide rail high-precision linear guides  ,ball screws transmission.

3. High speed milling water cooling spindle, it can mill and engrave,

so that can satisfy different demands of different materials, for example,metal and stone.

4. Easy servo motor,better accuracy than stepper motor

Model

ZK-3030

ZK-6060

Working size

300*300mm

600*600mm

Z-axis travel area

80mm

150mm

Max.feeding height

200mm

200mm

Spindle power

2.2/3.0/4.5Kw,24000rpm/min

Spindle cooling mode

Water cooling

Collects diameter

3.175mm-12.7mm

Control system

(Ncstudio control system, others optional)

Working voltage

AC220V/380V-50Hz

Repositioning precision

±0.03mm

Moving mode

easy servo motor

Net weight

800kg

1300kg

Cooper, alumium, cast iron, non-ferrous metals and metallic materials, suitable for carving a variety of metal molds.

Two-color plates, synthetic glass, acrylic, wood, wooden fish stone, rubber, marble, granite, tiles, shells and other non-metallic materials.

1. T/T 30% In advance, 70% before shipment

we are a professional manufacture for cnc routers, and we also a professional sales department that can help you to import good machines from us.

If you want some special models machines, also can contact with me, our engineer will

help you.
