Машина для выдувания экструзионной пленки
- Категория: Blown Film Production Line >>>
- Поставщик: Ruian,Chuangli,Machinery,Factory
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 10710.49 $* | 11246.65 $* |
| Aug-16-2025 | 10620.76 $* | 11151.30 $* |
| Jul-16-2025 | 8910.7 $* | 9356.34 $* |
| Jun-16-2025 | 10440.66 $* | 10962.62 $* |
| May-16-2025 | 9090.0 $* | 9545.24 $* |
| Apr-16-2025 | 10260.71 $* | 10773.70 $* |
| Mar-16-2025 | 10170.28 $* | 10679.68 $* |
| Feb-16-2025 | 10080.51 $* | 10584.63 $* |
| Jan-16-2025 | 9990.82 $* | 10490.84 $* |
Характеристики
HDPE/LDPE Film Blowing Extrusion Machine is used to produce plastic film made of low density polyethylene(LDPE),high jdensity polyethylene(HDPE).Linear low density polyethylene(LLDPE)and metallocene linear low density of package of civil and industrical products such as food,garment,tectile and daily necessities etc.
/Model | SJ-45 | SJ-50 | SJ-55 | |
Features | Raw Material | HDPE, LDPE, LLDPE; Virgin and Recycled | ||
Film Width | 400mm | 600mm | 800mm | |
Output | 25Kgs | 35Kgs | 45Kgs | |
Film Thickness | 0.008mm-0.15mm | |||
Power supply | 380V, 3Phase, 50Hz | |||
Weight | 1300kg | 1400kg | 1600kg | |
Dimension | 5×2.3×4M | 5×2.3×4M | 5×2.5×4.5M | |
Extrusion Unit | Screw&Barrel Diameter | 45mm | 50mm | 55mm |
Screw&Barrel L/D ratio | 28:1; 30:1 or 32:1 | |||
Motor | 11KW | 11KW | 15KW | |
Gearbox | 133 | 133 | 146 | |
Die Head Type | Fixed Die Head | |||
Die Size | 50/80 | 60/100 | 120/160 | |
Heating | 11KW | 11KW | 13KW | |
Blower | 2.2KW | |||
Film Taking-up Tower | Upper Tower Type | Rise and Fall | ||
Roller Length | 700mm | 700mm | 900mm | |
Roller Working Way | Opened and Tightened By Air Cylinders | |||
Take Up Motor | 1.5KW | |||
Winding Station | Winder Type | Single winding station | ||
Rollers | 700mm | 700mm | 900mm | |
Torque Motor | 5N/M | |||
Max. Winding Diameter | 600mm | |||
Control Panel | Temperature control | 5 zone | ||
Electronics | Top China Brand | |||
Inverter Capacity | 11KW/1.5KW | 11KW/1.5KW | 15KW/1.5KW | |
Optional Equipment | Hopper loader | |||
