hot sales in Russia hydraulic post hole digger for tractor used

Raymond earth auger is a kind of post hole attachments which is mainly used in skid steer loaders, mini loaders, mini excavators, backhoe loaders, telescopic handler, wheel Loader and other machinery.

It usually applicated in exploration and research,groundsource heat pumps,Fence,landscaping,tree planting,Well boring,foundation piles,screw pile installation,pole and mast installations,road signage,



Good feedback from our customers

Features



1.Forged hoods ears: Deal with the heavy strain of daily use.Contact surface wider and safer.

2.Eaton Motor: Developing the most reliable attachments .

3.ERICYLIC gearbox: Unique planetary gearbox.Multiplied output torque.

Extreme efficiency

4. NON-dislodgement shaft: Assembled top down locked into earth drill house.Never fall out.Provided a safer environment.



 18 Month After-sales service for auger drive.





Model	Carrier(T)	Torque (Nm)	Pressure (Bar)	Flow (L/m)	Rotate Speed (Rpm)	Output Shaft (mm)	Hydraulic Hoses (Inch)	Unit Weight (kg)	Unit  Height (mm)	Unit Max.Dia.(mm)	Auger Series
REA2000	1-2.5	≤1871	≤205	23-53	40-92	Ø65	1/2	54	595	200	S4
REA2500	1.5-3	≤2432	≤205	30-61	40-82	Ø65	1/2	54	595	200	S4
REA3000	2-3.5	≤2877	≤240	30-61	40-81	Ø65	1/2	71	700	244	S4
REA3500	2.5-4.5	≤3614	≤240	30-68	32-72	Ø65	1/2	71	700	244	S4
REA4500	3-5	≤4218	≤225	38-76	32-64	Ø65	1/2	71	700	244	S4
REA5000	4.5-7	≤5056	≤240	38-76	29-58	75	1/2	108	780	269	S5
REA5500	5-7	≤5901	≤225	45-83	28-50	75	1/2	108	780	269	S5
REA6000	6-8	≤5793	≤275	45-106	34-80	75	3/4	110	850	269	S5
REA7000	7-10	≤6931	≤260	61-121	37-72	75	3/4	112	850	269	S5
REA8000	8-12	≤8048	≤240	61-136	29-64	75	3/4	115	850	269	S5
REA10000	10-13	≤10778	≤240	70-136	22-43	75	3/4	167	930	290	S6
REA12000	13-17	≤11976	≤240	80-151	20-39	75	1	167	930	290	S6
REA15000	13-17	≤15046	≤240	80-170	17-34	75	1	167	930	290	S6
REA20000	13-20	≤19039	≤240	80-170	17-34	75	1	185	930	290	S6
REA25000	15-23	≤24949	≤250	90-180	16-30	75	1	185	930	290	S6







 How to choose the right model?

1.The weight of your excavator/tractor/ Backhoe/Skid Steer loader?

Model of Excavator	Weight of excavator	Model of Earth Auger
Cat226B	2.6T	REA2500,REA3000
Cat279C	4.5T	REA5500,REA5000
PC100	10T	REA8000
PC320	23.7T	REA20000,REA25000

2.Diameter and the Depth of hole to be drilled?

Diameter	Depth
From 100mm to 1200mm	We can Provide the extension shaft

3.Ground type to be drilled?

Earth Teeth and Pilot	Tungsten Teeth and Pilot	Rock Teeth and Pilot
Soil,Clay	Sandy soil,Gravel Soil	Rock and Pitch
