Select CE Certificate!! LW Series backhoe loader with price, best backhoe loader, 3 point hitch backhoe on Sale is smart chose





·Application: digging, trenching, material handling and back-filling,ect.

·Advanced Design, excellent performance, low maintenance costs,

·PTO Hydraulic System, Total Machine Control (TMC)

·Attachment-carrier options offering one-of-a-kind control and versatility: General bucket, Hydraulic thumb(optional )





Shandong Sunco Agricultural Equipment Technology Co., Ltd. is a wholesale distributor of front end loaders, Loader backhoe, construction and mining equipments.



It is a holding company of Shandong Academy of Agricultural Machinery Sciences (SAAMS), establised as The Technology Centre and Trial Production Factory of SAAMS in 1959 and founded officially in 2009. Our company occupied a totoal area of 270,000 sqm, and has staff of about 200, including more than 80 engineers and technicians. We have strong technique power, complete manufacture and test equipment, as well as advanced research and Development means of CAD. Our poducts includs: Front End Loader, Backhoe, Snow Removing Machineries (like Snow Blade, Snow Sweeper, Snow Blower, etc.), Forestry Machineries ( like Log Trialer with Crane, Log Splitter, Wood Chipper etc.), Front Linkage and PTO, Grass Mower, Dozer Blade and Compost Turner, etc.

Matching Tractors in domestic and overseas: Lovol (Foton),YTO, Chery Jinma, Enfly DQ, John Deere, New Holland, Kubota, Massey Ferguson, Belarus Minsk, Deutz ,etc.

Pls notice the specification below is for standard LW Series 3 point backhoe and LW Series Side Shift backhoe, and it is for reference only. If you want to buy nonstandard backhoe, pls contact us, we Provide customized service for you.

Specifications and engineering desighs are subject to change without notification



Specification of LW Series 3 point backhoe and LW Series Side Shift backhoe



Backhoe Model			LW-5	LW-6	LW-6E	LW-7	LW-7E	LW-8	LW-8E	LW-10	LW-10E	LW-12
Matching Tractor		hp	15~25	20~35		30~55		50~90		70~120		100~180
Max.Digging Depth	A	mm	1650	2000		2400		2800		3200		3655
Max.Unloading Height	B	mm	1530	1860		2050		2380		2650		3627
Max.Digging Height	C	mm	2600	2970		3210		3460		3770		5040
Working Radius	D	mm	2300	2700		3140		3600		3920		4510
Ground Clearance	E	mm	450					500				700
Side Shift Distance	F	mm	0	0	770	0	770	0	1000	0	1200	0
Min.Transporting Width	G	mm	1150	1700	1470	1700	1470	1700	1700	1850	2000	2100
Max.Width of Supporting Legs	H	mm	2100	2200	1470	2200	1470	2200	1700	2300	2000	2550
Bucket Width		in.	14			16		18		20		22
Bucket Capacity		m3	0.03	0.03	0.04	0.05		0.06		0.07		0.13
Weight		kg	360	550	600	560	620	630	700	800	1000	1500
PTO Hydraulic System	6/8/21 Splines(Option)
Thumb Grab	Option





For more detial information of LW Series 3-point Backhoe, pls feel free to contact
