Медицинское оборудование для больницы 100 мА диагностическое мобильное цифровое

 The machine is especially suitable for photography without power supply, such as special outdoor environment and emergent incidents.

Power Output: 5KW

Main Inverter frequency:50 KHz

X-ray Tube: fixed anode focus: 1.5 (X-ray tube for high frequency)

Tube Voltage: 40kV~~120KV (interval 1KV)

Tube Current: 25mA~~100mA

40~49kV     100mA     1~180mAs

50~59kV     77mA      1~140mAs

60~69kV     64mA      1~125mAs

70~79kV     55mA      1~110mAs

80~89kV     49mA      1~100mAs

90~99kV     44mA      1~80mAs

100~109kV   32mA      1~63mAs

110~120kV   25mA      1~50mAs

mAs          1.0~180mAs (46steps)

Power Supply: 220V±10%   50Hz   Inner-resistance ≤1.0Ω

Operation Method: Wire/wireless control

Standard configurations:

1. Combined high-frequency high-voltage X-ray generator and high-frequency inverter power supply (5kW, 120kV, 50 kHz)                                                                                       1 set

2. New mobile X-ray photography mainframe                               1 set

3. Mobile X-ray photography control system                                1 set

4. Rotating beam limiting device                                                  1 set

5. Remote control                                                                      1 set

6. Spare parts (See spare parts list for detail information)              several

 Features:

                          Stable, Compact, Convenient

1. With new design of compact appearance and flexible movement, it owns all the advantages of high frequency mobile x-ray photography machine.

2. It adopts the patent technology of automatic and single-arm support. The appearance is more beautiful and operation is more convenient.

3. With high frequency inverter to emit high quality X-ray and low dose on skin, and ensure excellent definition and contrast of pictures

4. With techniques of KV analog closed loop control, mAs digital closed loop control and micro-processing real-time control to ensure precision and repeatability of the dose.

5. With kV, mAs two button adjustment, LCD display, multifunction of safety guard.

6. With 50 preset exposure programs, and can be modified and stored by the user for convenient operation.

7. With a high-quality knockdown X-ray generator to reduce irradiation, it is much safer to environment and operator.

8. With fault automatic protection setting and fault alarming display

9. The system can keep parameters automatic, in case losing data.

10. With a rotating beam limiting device to adjust the X-ray field and angle, so it can ensure accurate radiography results.

11. With high kV function, it has wide using range and good effect of photography.

12. The rocker can whirl to left and right in ±90°, so photography polarization is convenient and swift.

13. With high-performance high-capacity chargeable battery, it can take 200 films without power supply for once charging. The machine is especially suitable for photography without power supply, such as special outdoor environment and emergent incidents.

14. Manual control and remote control are used to expose. Wireless remote exposure control can penetrate barriers, which makes operation more convenient.
