1. INTRODUCTION



ES-F-D-M single folding manual step is to help passengers get into vehicles more conveniently. It may be applied on the car, public bus, taxi, ambulance, motorhome and caravan so on.

This series has many specifications to meet your various demands and the load capacity reaches 200 kg.

All these manual steps have got the CE certificate, so you may enjoy all the convenience our step brings to you.



2. ADVANTAGES

• Non-skid platform with small frames and soft lines
• Easy operation by the driver or attendant.
• Light aluminum frame
• 200kg load capacity and 250kg test weight
• IP67 safety grade and CE certificate

3. SPECIFICATIONS

  (Unit:mm)



Model	Drive mode	Platform size (L*W)	Foot Step Width(S)	Mouting Bracket Witdth(T)	Horizontal  Mounting Hole Distance(U)	Load capacity	Own weight
ES-F-D-450-M	Manual	450×300mm	450mm	476mm	437mm	200KG	15KG
ES-F-D-600-M	Manual	600×300mm	600mm	626mm	587mm	200KG	25KG





4. APPLICATION

• Vehicle with sliding door, hinge door, electric door or plug door
• Cars, mini public bus or taxi
• Disabled cars
• Ambulance
• Minivans, caravan, motor home and camping car



5. INSTALLATION



(Mini inner space required to install)

Unit:mm

Model	Net width of door	Clear width under vehicle	Clear height under vehicle	Clear depth under vehicle	Remark
ES-F-D-450-M	450	480	420	530	The vehicle lengthways depth shall be not less than 510mm
ES-F-D-600-M	600	630	420	530



6. STANDARD PACKING LIST

• ES-F-M Manual Folding Step: 1 PCS
• Quality Certificate: 1 PCS
• User Manual: 1 PCS

7. WARRANTY

• 12 months warranty support.
• Every step has its own series number for after-sale track

8. SAFETY NOTE

• Never use the step if step retracted or half-retracted.
• The step shall be fully extended or retracted during working

(Full extended: when the connecting rod 1 touches the axle; fully retracted: when the connecting rod 2 touches the axle).
