Product details



Model	EG6060K
System	48V/4KW Series
Key Components	Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration)   Body and Frame             Frame Unitary welded steel framework S Body &Canopy FRP S Door Aluminum, 4pcs         O F/R bumper Carbon steel         S Floor artificial leather, red carpet       S Side trim FRP         S Foot step Aluminum         S Dashboard FRP         S Front Windshield Laminated windshield       S Rear Windshield toughened glass         S Seat Sponge+super-fibre leather+wood bottom S Side rear view mirror Two pieces per cart, chrome coated S Electric system             Lighting system and horn 2 headlights,  2 front turn signals, 2 front fog lights, 2 taillights( each combined 1 brake light with 1 turn signal and 1 fog light), with insulated DC-DC converter (converting from 48V/60V to 12V), air-horn.  S Reversing alarm \\ S Dashboard speedometer, amperemeter, voltmeter S Audio System Radio and MP3 receiver S Charger On-board charger, input 110V-240V~50Hz-60Hz, output 48V/22A S Steering and Suspension             Steering system Single-stage rack and pinion steering system, automatic rocker compensating function S Brake system Dual cycle 4-wheel hydraulic front disc rear drum brake with hand brake S Accelerator Stepless speed change S Suspension system Front: Independent macphersan suspension system  S Rear:  Non-independent suspension system  S Driving mode Rear axle two stage deceleration, motor direct driving S Rear axle Gear ratio 12.49:1 S Wheel & Tyre 6J*15 steel rims with cover & 185/65R15 vacuum tires S
Battery	8pcs T105 (185Ah@5hr)
Motor	4KW Chinese motor
Controller	Curtis 1205 (350A @ 2 minutes)
Performance
Passenger capacity	6
Range (loaded) based on flat road at a speed of 20km/h (km)*	≥70
Max. speed  (km/h)	≤25
Minimum turning radius (m)	6.3
Max. climbing ability (loaded)	15%
Max. movement after brake at speed of 20km/h	≤4m
Max. loading weight	480kgs
Net weight	1000kgs
Dimensions
Overall dimensions (mm)	4400X1650x1850
Min. ground clearance (mm)	120
Wheelbase (mm)	2900
Front wheel tread (mm)	1385
Rear wheel tread (mm)	1385
