Многоцелевой Монокуляр ночного видения Gen2 MHB для защиты безопасности оптическое ночное стекло 1X 3X 5X призматический
- Категория: Night Vision >>>
- Поставщик: Shenzhen,Ronger,Optics,&,Electronic,Technology,Development,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.0 $* | 0.94 $* |
| Aug-19-2025 | 0.28 $* | 0.73 $* |
| Jul-19-2025 | 0.13 $* | 0.96 $* |
| Jun-19-2025 | 0.58 $* | 0.53 $* |
| May-19-2025 | 0.90 $* | 0.12 $* |
| Apr-19-2025 | 0.43 $* | 0.31 $* |
| Mar-19-2025 | 0.59 $* | 0.36 $* |
| Feb-19-2025 | 0.13 $* | 0.61 $* |
| Jan-19-2025 | 0.58 $* | 0.8 $* |
Характеристики
PRODUCT OVERVIEW
The ruggedly designed tactical MHB series night vision monocular features automatic brightness control, integrated IR iluminator, IR-On and low battery indicators to achieve high performance.
This durable and reliable monocular are widely used in many Special Force around the globe. It could be combined with 3x or 5x magnification fier lenses to further extend the viewing capability.
FEATURES
- Lightweight
- Easy to operate
- Hand-held, head and weapon mountable.
- Allowing for ACH/MICH helmets mountable.
- Photo and video equipment adaptable.
- Automatic brightness control.
- Internal low battery and IR-on indicators.
- Protected against excess light exposure.
- Integrated(5MW IR iluminator.
- Comfortable for prolonged wear.
- Waterproof, corrosion and dust-resistant.
- May be equipped with a wide variety of optional accessories like 3x or 5x magnifier lens, weapon mount, demist shield, sacrifice window, day scopes couple and many others.
| Specification | |
| Model | MHB |
| Magnification | 1X |
| Field of view | 40° |
| Lens system | 26. 8mmF/1.2 |
| Focus range, m/in | 0.25 / 10" to infinity |
| Eye relief distance | 15 mm |
| Diopter setting, D | +5, -5 |
| Overall dimensions, mm/in | 115*62*42 / 4.5"x2.4"x 1.7 |
| Weight w/out headgear, g/oz | 330 / 11.6 |
| Power supply | 1 AA batteries 1.5V/1 CR123 |
| Estimated battery life w/out IR, 73°F, hour | AA-up to 40, CR123-up to 80 |
| Image Intensifier Tube | |
| Photocathode type | 18mm S-25 |
| Photocathode sensitivity, typical, μA/lm | 600-900 |
| Resolution, typical, lp/mm | 48-58 |
| Luminous gain, typical, fl/fcd | 19000 - 30000 |
| Signal-to-noise ratio, typical | 20:1 or better |
| FOM, typical | 1150 - 1350 |
| Tube relibility standard, hour | 10000 |
| Keep time, typical, year | 10 |
| Warranty, year | 1 |
| Effective Distance | |
| Detection range, approx, m/yard | |
| -quarter moon | up to 190 |
| -cloud cover | up to 170 |
| Recognition range, approx., m/yard | |
| -quarter moon | up to 150 |
| -cloud cover | up to 125 |
| 5mW IR iluminator, approx., m/yard | up to 30/12 |
| Environmental Data | |
| Operating temperature, °C/F | -40° to +50*/-40° to +122° |
| Storage temperature, °C/°F | -30° to +50°/-86 to+122° |
| Immersion, hour | 1 meter for 0.5 (Optional) |
| Humidity, % | up to 98% |
