Прямая продажа с завода, металлический ручной токарный станок
US $2000-$10000
CD6241 52 мм шпиндель отверстие ручной двигатель токарный станок с CE для
- Категория: Lathe >>>
- Поставщик: WMT,CNC,Industrial,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 5819.94 $* | 6110.1 $* |
| Aug-17-2025 | 5770.82 $* | 6059.72 $* |
| Jul-17-2025 | 4841.88 $* | 5083.5 $* |
| Jun-17-2025 | 5672.3 $* | 5956.67 $* |
| May-17-2025 | 4939.8 $* | 5186.31 $* |
| Apr-17-2025 | 5575.26 $* | 5854.72 $* |
| Mar-17-2025 | 5526.3 $* | 5802.76 $* |
| Feb-17-2025 | 5477.85 $* | 5751.37 $* |
| Jan-17-2025 | 5428.48 $* | 5699.59 $* |
Характеристики
Product Description
52mm spindle bore CM6241 cheap heavy engine lathe machine with CE for sale.
Features:
Super voice frequency heated bedways cheap cnc lathe machine
Hardened and grounded gears in the headstock
With 2 precision D degree taper roller bearings on the spindle
Integrated deluxe cast iron floor stand
Tolerance test certificate, test flow chart included
Specification | CM6241×1000 /1500mm |
Swing over bed | 410mm |
Swing over cross slide | 255mm |
Swing in gap | 580mm |
Length of gap | 19mm |
Distance between centers | 1000mm /1500mm |
Center height | 205mm |
Width of bed | 250mm |
Spindle nose | D1-6 |
Spindle bore | 52mm |
Taper of spindle bore | MT6 |
Range of spindle speed | 16 changes 45-1800r/min |
Travel of compound rest | 102mm |
Max.travel of cross slide | 210mm |
Leadscrew pitch | 4T.P.I. |
Max.Section of tool | 20×20mm |
Longitudinal feeds range | 0.05-1.7mm/rev(0.002-0.067/rev) |
Cross feeds range | 0.025-0.85mm(0.001-0.0335/rev) |
Cross feeds range | 0.025-0.85mm(0.001-0.0336/rev) |
Inch threads range | 45kinds 2-72T.P.I |
Diametrical pitches range | 21kinds 8-44D.P. |
Module pitches range | 18kinds 0.3-3.5M.P. |
Dia.of tailstock sleeve | 50mm |
Travel of tailstock sleeve | 120mm |
Taper of tailstock sleeve | MT4 |
Power of main motor | 2.2/3.3kw(optional 3.0/4.5kw) |
Power of coolant pump | 90w |
Overall dimension | 1940/2440×850×1300mm |
Packing size | 2060/2560×900×1640mm |
N.W/G.W | 1500/1750kgs 1550/1800kgs |
Products Show
