Best quality sunflower oil production line

Suitable material:peanut, soybean, rapeseed, sunflower seed and such oil material.

processing process sunflower oil production line

flow chart

1.Cleaning sunflower oil production line

In order to obtain high effective cleaning, ensure good work condition and production stability, high efficient vibration screen was

used in the process to separate big and small impurity.

Suction type gravity stoner removing machine was applied to remove the shoulder stone and earth, and magnetic separation

equipment without power and exhaust system were used to remove iron.

Dust removing wind net is installed. soybean oil machine

2. Flaking

Flaking means a certainty granularity of soy lamella was prepared for flaked of about 0.3 mm, the oil of raw material can be

extracted in the shortest time and maximum, and residual oil was less than 1%.

3. Cooking

This process is heating and cooking for rapeseed which is easy to separate of oil and can provide the oil quantity from

pre-press machine.It is easy to operate and have long life. soybean oil machine

4. Oil press machine

soybean oil extraction machinery's oil extraction is continuous screw press machine which is suitable to

the plant oil materials which has high oil content. oil extraction plant

The instruction of the cake is loose and easy to make the solvent permeate ,the oil content of cake and

moisture used for solvent extraction.

5. Crude oil refining

Oil refining is according to the different usage and requirements, utilizing the physical methods and chemical

processes to get rid of the harmful impurities and needless substance in the crude oil, getting standard oil.

Main economic and technical parameters of sunflower oil production line

Residual oil in meal	≤1% (soybean)
Solvent consumption	≤3Kg/T(6#solvent oil)
Crude oil moisture and volatile matter	≤ 0.30%
Power consumption	≤ 15KWh/T
Steam consumption	≤280Kg/T (0.8MPa)
Finished meal moisture	≤ 10-13% (adjustable)
Residual solvent in finished meal	≤ 300PPM (qualified detonated experiment)
