FZP металлический шариковый фиксатор стальная шариковая клетка

Описание и отзывы

Трекер стоимости

Характеристики

FZP metal ball retainer ,steel ball cage,ball bearing





Material Features

FZH,FZL,FZP ball retainer are as copper, aluminum, POM base.They are machined some regular holes and embedded the steel-ball into.The new work-craft will prevent the ball getting out of as old,as the ball diameter is larger than the retainer's thickness, so it will face to face directly with 90º guide bushing,that will bring high precision match now the ball retainer series items are designed to rotate on the post,as well as maintain its vertical motion.We believe this will give you the benefit of increasing accuracy.



Specification

performance index	data
max load capacity P	30N/mm²
assembling shrink	0.01mm~0.02mm
max.sliding speed V	6m/s
friction coef	0.01~0.08
deviation of the steel ball diameter	<0.01





Advantages and application

As the traditional work-craft has some grudge between bushing with posts,and the coefficient of friction is larger.now we have changed the work-way to steel-ball directly face to face guide bushing,so the precision is improved.it composes of both active roll and lower friction coefficient,now they have been widely used in punching machine,die machine,high precision machine which need rotation and vertical motion.



Picture showing



Factory

Our factory is located in the centre of Yangtze economy delta zone with convenient transportation, specialized in research, study and producing of self-lubricated bearings.

Our factory is equipped with advanced production and inspection line and managed by a high tech group.

Our factory dedicated in study and producing serials self-lubrication bearings which could be used in all sorts of condition respectively with high performance.

Our factory is looking forward to have an opportunity to work and cooperate with you.







Our services

1.Sample order is available

2.Small order is acceptable

3.Customized is available as per drawing or sample



Original documents

1.B/L(bill of lading )

2.C/O(certificate of origin )

3.Commercial invoice

4.Packing list



After-sale service

1.Goods quality following

2.Accept feedback and solve the problem

3.Regular return visit









We are at service in 24 hours.
