1. Overview

Fluidic Oscillation Gas Meter is a residential gas meter with art-state compact design from Viewshine’s

F-Series gas meter. the F-GR is rated from 0.04~1.6m³/h of gas at 1Kpa pressure loss across gas meter.

No Mechanical moving parts, full-electronic metrology and temperature compensation drive all combine to give superior accuracy retention and stability.



2. Feature

>long-term stability, no mechanical moving parts

>compact design

>automatic temperature compensation

>pulse output



Specification

ITEM	UNIT	MODEL
		F-GR1.6
Qmax	m³/h	1.6
Qmin	m³/h	0.04
Pressure	KPa	0.5~5
Pressure loss	Pa	100
Accuracy	Class	1.5
Operation Temperature	℃	-10~40
Humidity	%	RH93%
Protection		IP53
Compensation		Temperature
Power		Li-battery
Weight	Kg	0.5
Dimension	mm	110*95*77
Approval		GOST NO.51758-12



ZHEJIANG WEIXING INTELLIGENT METER STOCK CO,.LTD

Building 6, No 1418-41, Moganshan Road, Hangzhou, China

www.viewshine.com.cn
