Батарея управляемая тележка для поддонов/горячая Распродажа Heli 3-х Тонный Электрический вилочный погрузчик
- Категория: Material Handling Equipment >>>
- Поставщик: Evangel,Industrial,(Shanghai),Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 9520.62 $* | 9996.92 $* |
| Aug-19-2025 | 9440.65 $* | 9912.34 $* |
| Jul-19-2025 | 7920.25 $* | 8316.63 $* |
| Jun-19-2025 | 9280.61 $* | 9744.89 $* |
| May-19-2025 | 8080.15 $* | 8484.70 $* |
| Apr-19-2025 | 9120.89 $* | 9576.32 $* |
| Mar-19-2025 | 9040.56 $* | 9492.74 $* |
| Feb-19-2025 | 8960.85 $* | 9408.71 $* |
| Jan-19-2025 | 8880.16 $* | 9324.57 $* |
Характеристики
battery operated pallet truck/hot sale electric forklift
Product Description
Speciality parameter | Model | CPD20 | ||||
| Power type | Battery | |||||
| Rated capacity | kg | 2000 | ||||
| Load center | d | mm | 500 | |||
| Lift height | h2 | mm | 3000 | |||
| Mast tilt angle (forward/backward) | α/β | Deg | 6/12 | |||
| Front overhang | L3 | mm | 483 | |||
| Wheel-base | L4 | mm | 1500 | |||
| Tread(front/rear) | b4/b5 | mm | 970/950 | |||
| Performance parameter | Travel brake | Hydraulic-Foot pedal | ||||
| Parking brake | Mechanical-Hand lever | |||||
| Lift speed(with/without load) | mm/s | 260/400 | ||||
| Lower speed (with/without load) | mm/s | (with load)300 | ||||
| Travel speed (with/without load) | km/h | 11/12 | ||||
| Max. gradeability (with load) | % | 1 | ||||
| Power, transmission and others | motor | Driving motor | Model | XQ-6.3-1T | ||
| Rated power | kw | 6.3 | ||||
| Rated rotation | r/min | 1200 | ||||
| Working motor | Model | XQD-8.6-C | ||||
| Rated power | kw | 8.6 | ||||
| Rated rotation | r/min | 1550 | ||||
| Controller | Manufacturer | GE | ||||
| Type | MOSFET | |||||
| Battery | Voltage | V | 48 | |||
| Capacity | Ah | 630 | ||||
| Size(L×W×H) | mm | 820×1065×520 | ||||
| Gearbox | Transmission type | Mechanical | ||||
| Tire | type | Pneumatic tyre | ||||
| Model | Front | 7.00-12-12PR | ||||
| Rear | 18×7-8-14PR | |||||
