Батарея 11 местный Электрический экскурсионный электромобиль на продажу (LT-A8 +

Electric system

controller

1268/400A

battery

8V,6 units

motor

KDS48V/3.7KW motor

charger

Computer Intelligent,input 220V/110V,ourput 48V,20A

Charging time

Less than 12 hours(discharging rate 80%)

Body configuration

Glass

PC  glass

Sun Roof

ABS  Vacuum forming

seat

leather

Floor

Autiskid rubber floor

Rear mirror

Handoperated,both side

Steering

Dual automotive-style strut and self-adjust rack-and pinion steering

DC/Light/Signal

48V/12V-300W   Front light turning light,rear light,horn,Buzzer

Body

PP  Vacuum forming

Dash Board

PP  Vacuum forming,Voltage Indicator 48V,Switch Head Lights,Switch - Indicators Right/Left,key switch,Switch - Forward/Reverse

Braking system

Rear drum brake+compound pedal brake

Front axle and suspension

Independent suspension,helical spring +cylinder hydraulic shock absorption

Rear axle and suspension

Integral type transaxle,gear ratio 12.31:1,semi-independent transaxle,spring,cylinder hydraulic shock absorption

Tire diameter

452mm

Parameter

Length*width*height

4200*1200*1900mm

Loading passenger

11

Max speed km/h

22km/h

Mileage

/km

70—80km(flat road)

Max climbing ability

15%

Mini turning radium(m)

5m

Mini ground clearance

110mm

Wheel base

Front 930/back 1010mm

Braking distance

5.5M
