Внутренняя стеновая панель из сосновой древесины
US $2.71-$2.73
Поставщик сэндвич-панелей PIR
- Категория: Building Boards >>>
- Поставщик: DANA,WATER,HEATERS,&,COOLERS,FACTORY,(L.L.C.)
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.95 $* | 0.42 $* |
| Aug-19-2025 | 0.49 $* | 0.90 $* |
| Jul-19-2025 | 0.98 $* | 0.23 $* |
| Jun-19-2025 | 0.89 $* | 0.1 $* |
| May-19-2025 | 0.17 $* | 0.94 $* |
| Apr-19-2025 | 0.41 $* | 0.44 $* |
| Mar-19-2025 | 0.35 $* | 0.48 $* |
| Feb-19-2025 | 0.39 $* | 0.92 $* |
| Jan-19-2025 | 0.81 $* | 0.31 $* |
Характеристики
Product Description
Insulation Specification
- Thermal Conductivity Value : Amount of heat (W) passing through a material having surface of 1 M2 and thickness 1 M in order to rise temperature by 1oC . Units are W/m K
- K value (Insulation Value) : Thermal conductivity divided by thickness of the material [ W / m2 K]
- U value (Total Insulation Value) : Also known as Overall Heat Transfer Coefficient determined by the insulation value of the various materials forming the panel . [ W / m2 K ] , KCal/m2 h oC , BTU/ F t2 h oF
| On Continuous System | Density | K value |
|---|---|---|
| Polyisocyanurate (PIR) | 40-45 Kg/m3 | 0.022 w/m2K |
Please note : Lower the K value , better is insulation capability
Polyisocyanurate (PIR) Foam Properties
- Mechanical Characteristic of Foam
| Density | 40-45 kg/m3 (as per BSEN 1602:1997) |
| Tensile Stress | Greater than 100 kpa (as per BSEN 1608:1997) |
| Compression Resistance | Greater than 100 kpa (as per ASTM C165 :2000) |
| Shear Resistance | >100 kpa (as per ASTM 271/271M) |
| Fire Property | B2/ B3 as per DIN 4102-1 |
- Overall Heat Transfer Coefficient (U) Value -W/m2 K
| Thickness in mm | 35 | 40 | 50 | 60 | 75 | 100 |
| Overall Heat Transfer Coefficient (U) | 0.67 | 0.60 | 0.47 | 0.40 | 0.31 | 0.24 |
Company Information
DANA STEEL UAE ( Est. 2001) - A Division of DANA Group
DANA Steel UAE is the Iron & Steel Division of well re-knowned DANA Group . Established in 2001, it started with humble beginnings of a Coil Service Centre Where Flat Steel ( Hot Rolled,Cold Rolled,Prepainted Galvanized,Stainless Steel,Galvanized Steel) were processed.Over the Years it has evolved to become one of the Largest VALUE-ADDED Steel manufacturers of the Region.It Now manufactures a Wide Range of Processed Steel Products :-->
* 4 Branches in UAE ( 2 - Ajman, 1 - UAQ, 1 - Dubai)
* 6 Diversified Divisions
* ISO 9001:2008 Certified
* Professional Management
* Exporting to more than 40 Countries WorldWide
Coil Service Center Division
Under it’s expansion plan, DANA group established it’s extended coil service centers located in Umm-al-quwain,Ajman & Dubai which has imported machinery to handle thicknesses in the range of 0.30mm -18 mm. With a max coil load capacity of 30 MT, it’s one of it’s kind.
Under it’s expansion plan, DANA group established it’s extended coil service centers located in Umm-al-quwain,Ajman & Dubai which has imported machinery to handle thicknesses in the range of 0.30mm -18 mm. With a max coil load capacity of 30 MT, it’s one of it’s kind.
Cable Management System & Rollformed Products Manufacturing Division
Adding to it’s Value Added Services, DANA group started manufacturing of Cable Management Systems,with most modern plant & infrastructure.The product range includes Cable Trays,Cable Ladders, Trunkings & accessories,which are supplied to various Power Plants, Electricity Boards, Engineering Organisations and many other Projects.Besides cable management systems we are also manufacturing various value-added rollformed products like strut channels,drywall metal profiles(studs/tracks/furring channels,hat channels),gi lintels,purlins and perforated sheets.
Adding to it’s Value Added Services, DANA group started manufacturing of Cable Management Systems,with most modern plant & infrastructure.The product range includes Cable Trays,Cable Ladders, Trunkings & accessories,which are supplied to various Power Plants, Electricity Boards, Engineering Organisations and many other Projects.Besides cable management systems we are also manufacturing various value-added rollformed products like strut channels,drywall metal profiles(studs/tracks/furring channels,hat channels),gi lintels,purlins and perforated sheets.
Profiles & Cladding Division( PEB Steel Buildings)
This Division is actively engaged in the manufacturing of Steel Buildings,insulated composite profiled panels, profiled cladding sheets, secondary structural members,C & Z Purlins,Composite Floor Decking Sheet ,Steel Buildings,Warehouses ,Wall Cladding Sheets, Roof Cladding Sheets,Corrugated fencing/hoarding panels, Curved Cladding Sheets, Flashing Sheets, Sandwich Panels(PUF/PIR/ROCKWOOL),Fencing Panels, Shinko Fence,Chainlink Fence, Flat Panels and Cold Store Panels and all kind of accessories.With the Acquisition of ETA Profiles LLC, the production capacity has increased manifold.
This Division is actively engaged in the manufacturing of Steel Buildings,insulated composite profiled panels, profiled cladding sheets, secondary structural members,C & Z Purlins,Composite Floor Decking Sheet ,Steel Buildings,Warehouses ,Wall Cladding Sheets, Roof Cladding Sheets,Corrugated fencing/hoarding panels, Curved Cladding Sheets, Flashing Sheets, Sandwich Panels(PUF/PIR/ROCKWOOL),Fencing Panels, Shinko Fence,Chainlink Fence, Flat Panels and Cold Store Panels and all kind of accessories.With the Acquisition of ETA Profiles LLC, the production capacity has increased manifold.
Guard Rails & Highway Crash Barriers Division
This Division is actively engaged in the manufacturing of highway crash barriers and guard rails for installation on various major highways/roads and infrastructure projects in UAE & surrounding Gulf Countries.
This Division is actively engaged in the manufacturing of highway crash barriers and guard rails for installation on various major highways/roads and infrastructure projects in UAE & surrounding Gulf Countries.
Fencing Division (http://danasteeluae.com/discontinuous-corrugated-steel-hoarding/)
DANA Steel is one of the largest manufacturer of high quality fencing solutions ranging from crowd barriers, construction site hoarding panels, boundary wall perimeter fence, temporary fences, shinko hoarding panels,heras ,chainlink fencing, concrete foundation blocks.We also have our inhouse expert installation team which does turnkey projects.
Steel Drums & Barrels Manufacturing Division (http://www.danasteeluae.com/steel-drums-barrels/)
DANA Steel has a fully automatic state-of-art drum manufacturing plant capable of manufacturing upto 1 million steel barrels annualy. We are manufacturing all kinds of steel drums & barrels in open top,closed,lacquer coated or clean coated variants with 2 or 3 color stove enameled paint and Logo stencil.Our Drums are distributed to various industries like chemical & paint manufacturers, lubricants and grease manufacturers, food products manufacturers.
FAQ
Q: Are you trading company or manufacturer ?
A: We are a well established factory with 4 well equipped production Facilties in the UAE ( United Arab Emirates), 2 in Ajman,1 in Dubai and 1 in UAQ(Umm-al-Quwain City).Established in 2001 ,and being the Iron & Steel Division of well reknowned DANA Group ,our products are proudly MADE IN UAE and exported to more than 40 countries worldwide.
Q: How long is your delivery time?
A: Generally it is 1-2 days if the goods are in stock. or it is 7-10 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What are your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:-
