Древесные чипы 50 кВт Биомасса генератор газификации цена газификации; 32665 5-100квт ISO9001 VEERA BIOPOWER нержавеющая сталь SVE50
- Категория: Other Energy Related Products >>>
- Поставщик: SAKTHI,VEERA,GREEN,ENERGY,PRIVATE,LIMITED
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 35700.49 $* | 37485.35 $* |
| Aug-18-2025 | 35400.81 $* | 37170.66 $* |
| Jul-18-2025 | 29700.91 $* | 31185.73 $* |
| Jun-18-2025 | 34800.99 $* | 36540.77 $* |
| May-18-2025 | 30300.37 $* | 31815.69 $* |
| Apr-18-2025 | 34200.16 $* | 35910.13 $* |
| Mar-18-2025 | 33900.30 $* | 35595.62 $* |
| Feb-18-2025 | 33600.56 $* | 35280.14 $* |
| Jan-18-2025 | 33300.18 $* | 34965.22 $* |
Характеристики
Product Description
In order to retain our goodwill in this industry, we are providing a latest array of Biomass Gasifier.
Veera Power offers biomass gasifiers and power generation systems at multiple levels of assembly and system integration.Our is very easy iinstall and operate , From “We deliver it turnkey complete .you decide the relative amount of effort vs cost you want to invest towards your finished system. We offer complete customer support and service, with a dedicated team available to answer your questions, trouble shoot your installation.
lb of wood at 15% moisture content produces 35 cubic feet of gas
4,900 BTU heat from burning the gas direct or
0.51 HP of shaft power (i.e engine) or
0.342 kW of electric power generated.
1 kg of biomass ~ 2 lbs biomass ~ 2m3 gas ~ 10,000 BTU
The main rule of thumb to remember for thermal equivalencies
TECHNICIAL DETAILS
| S.NO | DETAILS | VALUES OR TYPE |
| 1. |
Gasifier Type | Imbert Down Draft Gasifier |
| 2. | Starting Ignition | Automatic /Mannual |
| 3. | Capacity | 5-100KW |
| 4. | Coal Generated | 3-6% ( depends on biomass) |
| 5. | Fuel size | Maximum: Diameter50mm Length – 5-6cm (if other please specify) |
| 6. | Gas calorific value | 1100kcal/m3 |
| 7. | Maximum Biomass Consumption (Kg/KWh) | 1.1-1.6kg |
| 8. | Gasification Temp. (°C) | 950-1150c |
| 9. | Gasification Efficiency (%) | 60 to 75 % |
Gas Compositions (%): |
| |
1. | Carbon Monoxide | > 22 %, |
2. | Hydrogen | > 18% |
3. | Methane | >5 %, |
4. | Carbon Dioxide | < 11 % |
5. | Nitrogen | Rest % |
Feature gasifier
- Temperature Indicator
- Ash grates Auger Motor Control
- Sound proof (optional)
- No water for cleaning and cooling the gas
- Tar free
- Air pre heating technology
