4040 FRP резервуар под давлением для системы обратного осмоса и очистки воды мембранный корпус

Описание и отзывы

Трекер стоимости

Характеристики

Good quality,high performance,low price YB4040E-A-2 FRP housings:



1.FRP membrane housing with good quality
2.Suitable for different kinds of membrane
3.Easy to set up and keep

4.Excellent resistance to high pressure,it can be used for long time
5.Have a good after-sales service



Membrane components:
Suitable for Dow, GE, Koch, Hydranautics, Saehan, Toray, Vontron membrane components of other standards
Quality Assurance:

100% pressure vessels were tested with 1.2 – 1.5 times design pressure
100,000 times fatigue test
6 times design pressure burst test
100% pressure vessels have their own numbers, we can trace them



Performance parameter of YB4040E-A-2 series FRP membrane housings:

specification	YB4040E600A	YB4040E800A	YB4040E1000A	YB4040E1200A
series	A	A	A	A
vessel diameter	4 inch	4 inch	4 inch	4 inch
Membrane length	40 inch	40 inch	40 inch	40 inch
Port Design	End	End	End	End
Design pressure	600PSI	800PSI	1000PSI	1200PSI
Operating Temperature	-7°C—49°C	-7°C—49°C	-7°C—49°C	-7°C—49°C
Factory Test Pressure	900PSI	1200PSI	1500PSI	1800PSI
Operating PH Range	3-11	3-11	3-11	3-11
Cleaning PH Range	2-12	2-12	2-12	2-12
Number of Membrane	1-4 PCS	1-4 PCS	1-4 PCS	1-4PCS
