CU/CCS/CCA 50 Ом коаксиальный кабель lmr 240 с низким уровнем
- Категория: Communication Cables >>>
- Поставщик: Hangzhou,Otto,Cable,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-18-2025 | 0.89 $* | 0.69 $* |
| Aug-18-2025 | 0.11 $* | 0.45 $* |
| Jul-18-2025 | 0.14 $* | 0.22 $* |
| Jun-18-2025 | 0.54 $* | 0.83 $* |
| May-18-2025 | 0.34 $* | 0.32 $* |
| Apr-18-2025 | 0.41 $* | 0.64 $* |
| Mar-18-2025 | 0.94 $* | 0.94 $* |
| Feb-18-2025 | 0.67 $* | 0.40 $* |
| Jan-18-2025 | 0.6 $* | 0.15 $* |
Характеристики
LMR240
Construction
Item | Material | Diameter(mm) | Remarks |
Inner Conductor Dielectric First Shield Second Shield Jacket | Bare Copper Foam PE Bonded Aluminum Foil TC Wire Braid PVC | 1.42 3.81 3.94 4.52 6.10 |
|
Electrical Characteristics
Impedance (Ω) Capacitance (pF/m) Velocity of Propagation (%) Return Loss Screening Effectiveness(db) Voltage With Stand Installation Temp(℃) Operating Temp(℃) | 50±3 79.4 84.0 ≥20 ≥90 1500.0 -55 to +85 -55 to +85 |
Attenuation (@200C)
Frequency(MHz) | Max Attenuation(dB/100m) |
150 220 450 900 1500 1800 2000 2500 | 9.9 12.0 17.3 24.8 32.4 35.6 37.7 42.4 |
