Single phase STS prepaid token meter



As a professional manufacturer, YTL designs and produces electronic energy meters which are cost-efficient and ideal for the use in solutions for AMR/AMI at residential as well as industrial applications



YTL is devoted to develop and design all types of electronic energy meters, concentrators and solution applications. With a combined design of the special accessories, we have successfully developed series of competitive products of small size, multifunction, low power consumption and excellent performance. We offer a one-to-one service to our partners. With annually over 68 projects that are successfully finished and holding over 200 patents of design rights, we are also advanced in the technology and patents of current sampling.



1.Product Details
Product Name		Single phase STS prepaid token meter
Installation type		Suspensin type
Module No.		D124009 (prepaid token meter)
Brand		YTL (prepaid token meter)
Rated Current		5(60)A
Reference Voltage		110V  230V
Frequence		50HZ   60HZ
Display Mode		LCD
Accuracy		1.0
Impulse Constant		1000imp/kWh
Start Current		0.002Ib
Connection Mode		Direct type
Communication& Protocol		RS485 IR
Power Consumption		2VA
Material of meter case		PC
Size		171.5*106*54.5mm
Certificate		STS
Standard		IEC62052-11 IEC62053-21 IEC62056-21  IEC62055
2.Functions and characteristic
A. STS standard compliance It has the feature of low cost ,high reliability and safety. We have been the member of STSA.
B. Relay to disconnect when overload
C. Keay pad, easy to manage
…
3.Outer and mount dimension:
4.Wiring diagram:
5.Transaction Information
MOQ	500pcs
Sea Port	Shanghai
Payment Terms	TT prepayment
Supply Ability	50,000pcs per month
Delivery time	25 days
Normal Package	white box or colorful box for prepaid token meter







If you are interested in our Single phase STS prepaid token meter, pls be free to contact us at any time.
