33 YEARS HISTORY, 33 YEARS EXPERIENCE CUSTOMER FIRST, QUALITY BEST EXCELLENT TECHNOLOGY WITH PERFECT WORKMANSHIP To produce down coats,sports wear,swiming suits,tents,car covers,ect by using PVC,PU,3-Ply Cloth coating and non-woven fabric Application: Producing high-class down coats,sports wear,snow coat, rain coats, swiming suits,skiing dress, tents, waterproof covers, waterproof bags, hood covers, ship covers ect by using PVC, PU, Rubber ,3-Ply Cloth coating and non-woven fabric ==Product Features== |
Large soft-touch and multi-fuction display with high definition are chose for clear display of rate,temperature,operations and programming. Sealing speed, temperature and actions controlled by micro-computer, easy to be adjusted. Both the front length and tailed-end of the tape can be adjusted by computer according to customers' requirements. Tail-end of seam sealing tape can be both finished automatically and manual. When the working temperature is set, PLC is under the automatic control, The temperature fluctuation is allowed within+/-1°C, There is an alarming device for ceiling limit for safe and longer use of the fuse. In design, the exterior heating pipe is cooled by air for less possibility of burning workers and prolonging the life cycle. In design, the tape is loosened, conveyed and cut automatically by the motor for much less consumption of tape tail section and high quality of the products. Large and strengthened zigzag-rule structure provides efficient and flexible working space.
|
Power and Voltage: | AC220V±10%,50-60HZ. | Rating efficiency: | 2800W | Heat Control: | Room temperature ~700°C;adjustable without bands | Speed: | 2~18m/min,adjustable without bands | Gun nozzle pressure: | 0.03-0.2MPa Adjustable without bands (displayed by a pressure meter) | Nozzle width: | Standard Flat Nozzle 24mm | Pressure of upper pinch roller : | 0-0.2 Mpa Adjustable without bands(pressure meter display) | Pinch roller Width: | Standard:25mm mill finish,other width can be choosen according to specific demand | Seam sealing tape width: | Standard 14mm-22mm, other width can be tailored according to customer's requirements. | Upper roller lift : | 18~22mm | Exterior size: | 1350mm(L) x730mm(W) x 1900mm(H) | Net Weight: | 120kg | Prevention Against Jumping over Sewing Work: | There are adjustable devices to prevent the gun from jumping over the seamed sections when the gun is moving inward with the idle wheel starting , or when the gun moving outward with the idle wheel stopping |
|
