JKS-200 manual hydraulic hose crimping machine/manaual rubber hose crimping/hose crimping machine is a portable type of machine which is simply designed and convenient for operating and carrying. It takes manual pump of extra high pressure as power source. So it’s much suitable for the outdoor work and production of without electric power.



JKS-200 Hose crimping machine

2,Instruction



 Hose crimping machine is a portable type of machine which is simply designed and convenient for operating and carrying. It takes manual pump of extra high pressure as power source. So it’s much suitable for the outdoor work and production of without electric power.



3,Technical data



1,Specifications,            JKS-200

2,Hydro-cylinder pressure,     40  T

3,Displacement of oil pump,    30  ml

4,Hydraulic oil,              Summer, YB-N46

                                    Winter,B-N32

5,Crimping  range.           φ6——φ32mm

6,Weight,                    120  kg

7,Volume,                  600×500×370mm³

Operation o  Hose Crimping Machine



1. Release the pole (3) by the handle (random accessories), set the dies one by one, according to the number and clean the awl surface and flange. Put the side with letter foreword. Please make sure that the die marches the hose: the inner diameter of hose is the size mm of die.

2. Screw up the valve (10), and then tighten (7).

3. Lift (8) to put it on and then put down it. Repeat this movement and pay attention to the changing of the Pressure gauge (6) until it reaches 16.5MPa.The maximum pressure for swage should not pass 20MPa.

4. After swaging the hose, please revolve (10) and (7) in contrary direction. Then the dies will be released automatically. Take the swaged hose out.

5. Clean the machine after working and cover it with the plastic shelter.

Packing list



No.	Name	Dimension	Quantity	Notice
1	Dies		8
2	Oil gun		1
3	Oil box		1 --
4	Pull-rob		1
5	User’s manual		1



3,advantage:8 sets die,40ton crimping force,6-32MM crimping range, manual ,easy operate,

have operation video.



4, are appling CE certificate, factory founded in 1978 with more than 30 years experience.
