Автоматический регулятор/стабилизатор напряжения SDR SDR-1000VA
- Категория: Регуляторы/стабилизаторы напряжения >>>
- Поставщик: Yueqing,Heyuan,Electronic,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.8 $* | 0.71 $* |
| Aug-16-2025 | 0.54 $* | 0.80 $* |
| Jul-16-2025 | 0.23 $* | 0.9 $* |
| Jun-16-2025 | 0.98 $* | 0.81 $* |
| May-16-2025 | 0.24 $* | 0.27 $* |
| Apr-16-2025 | 0.69 $* | 0.23 $* |
| Mar-16-2025 | 0.25 $* | 0.76 $* |
| Feb-16-2025 | 0.9 $* | 0.80 $* |
| Jan-16-2025 | 0.52 $* | 0.80 $* |
Характеристики
SDR-1000VA Ac Automatic Voltage Regulator/Stabilizer
After-Sales Service
| Model | SDR- 500VA | SDR- 1000VA | SDR- 2000VA | SDR- 3000VA | SDR- 5000VA | SDR-10000VA | SDR-12000VA |
| Technology | Relay Control System+Micro compute programed control+control algorithm relay" Cross zero" | ||||||
| LED Display | Color | According to customer requirement,voltage stabilizer | |||||
| Info | Input Voltage/Output Voltage/Load Usage/Time Delay/Normal Working/Protection | ||||||
| Protection | Over Voltage | Output voltage ≥ 245v± 4 | |||||
| Over Loading | more than 120% | ||||||
| Over Temperture | 120° C± 10° C | ||||||
| Delay time | 3 second | ||||||
| Lauguage | English/Russia/Chinese | ||||||
| Input Voltage | AC140-260V | ||||||
| Output Voltage | 220V± 8% Adjustable | ||||||
| Frequency | 50Hz/60Hz | ||||||
| Phase | Single Phase voltage stabilizer | ||||||
| Efficiency | ≥ 90% | ||||||
| Ambient Temperature | -15° C~45° C | ||||||
| Relative Humidity | < 95% | ||||||
| Waveform distortion | no additional wave form distortion | ||||||
| Insulating Resistance | Normally more than 2MΩ | ||||||
| Power | 350W | 700W | 1400W | 2400W | 3500W | 7000W | 9600W |
| Packing Size(mm) | 575× 275× 380 | 575× 275× 380 | 355× 305× 450 | 355× 305× 450 | 515× 420× 310 | 460× 265× 310 | 460× 265× 310 |
| Packing | 8 | 8 | 4 | 4 | 2 | 1 | 1 |
| G. M | 19.52 | 23.12 | 21.92 | 23.32 | 22.72 | 15.90 | 18.70 |
Packaging information
Model | Unit(PCS) | Device Size(MM) | Package Size(MM) | G.W.(KGS) |
SDR-500 | 8 | 210*110*150 | 495*280*350 | 19.52 |
SDR-1000 | 8 | 210*110*150 | 495*280*350 | 23.12 |
SDR-1500 | 4 | 240*150*185 | 375*305*435 | 17.60 |
SDR-2000 | 4 | 240*150*185 | 375*305*435 | 21.92 |
SDR-3000 | 4 | 240*150*185 | 375*305*435 | 23.32 |
SDR-5000 | 2 | 340*220*250 | 515*420*300 | 22.72 |
SDR-8000 | 1 | 385*220*250 | 460*265*300 | 13.50 |
SDR-10000 | 1 | 385*220*250 | 460*265*300 | 15.20 |
SDR-12000 | 1 | 385*220*250 | 460*265*300 | 16.20 |
