DP-100 дифференциальный датчик
- Категория: Instrument Parts & Accessories >>>
- Поставщик: TECPEL,CO.,LTD.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.29 $* | 0.5 $* |
| Aug-16-2025 | 0.58 $* | 0.18 $* |
| Jul-16-2025 | 0.12 $* | 0.60 $* |
| Jun-16-2025 | 0.98 $* | 0.37 $* |
| May-16-2025 | 0.79 $* | 0.60 $* |
| Apr-16-2025 | 0.1 $* | 0.69 $* |
| Mar-16-2025 | 0.62 $* | 0.54 $* |
| Feb-16-2025 | 0.28 $* | 0.40 $* |
| Jan-16-2025 | 0.38 $* | 0.89 $* |
Характеристики
Differential probe Oscilloscope Probe
Product ID: DP-101
100 MHz Differential Probe
DP-101 ( 6.5KVp-p / 100MHz )
4 RANGE ATTENUATOR
2 POWER SOURCE
6500V HIGH VOLTAGE INPUT.
<6.5V LOW BATT. INDICATE
<5.5V AUTO POWER OFF
SEPARATING DESIGN, CONVENIENT, DURABLE
MEET IEC1010, UL3111, TUV GS, CAT III 6500V
SPECIFICATIONS
Differential Voltage DC + pk AC:6500V
Bandwidth ( 50 Ω load -3dB ):100MHz( x100 50MHz)
Common Mode Voltage DC + pk AC:6500V
Common Mode Voltage RMS CAT II:6500V
Common Mode Voltage RMS CAT III:6500V
Attenuation ( Switchable ):X 100, X 200, X 500, X 1000
Input R ( Each input ):27MΩ ± 1%
Input C ( Each input ):2.5 PF ± 2%
Maximum Operation Voltage( DC + pk AC )
± 650V at X 100
± 1300V at X 200
± 3250V at X 500
± 6500V at X 1000
Common Mode Rejection Ration
( C M R R )
60 Hz : > 20,000 : 1
100 Hz : > 2,000 : 1
1 MHz : > 600 : 1
Noise ( Into 50Ω load ): 1 m Vrms
Input Impedance ( between input):54 MΩ // 1.25 PF
Accuracy ( at 20 ~ 30 70% RH after 20 minutes ): ± 1.5 %
Product Description
Our quality products have been accepted by some well-known international customers. The confidence we have in our products is reflected in our one-year warranty and by our flat-rate service policy 3 through 5 years. Many of our products get CE approvals.
Packaging & Shipping
Shipment can be done within 14 days after receipt of payment for small quantity.
Our Services
Years of experience have taught us that to make our customers happy is to satisfy their every need. TECPEL continues to be a customer focused company and is committed to providing our customers with high quality, best price products with prompt services. All of this is combined to ensure your satisfaction.
Company Information
| Established in: | 1990 |
| Annual Sales: | 3 millions |
| Capital: | US$ 150,000 |
| Business Type: | OEM Manufacturer ODM Manufacturer Exporter/Agent Electronics Test and Measuring Instruments |
| Markets: | North America South America / Caribbean West Europe East Europe / Russia East Asia Southeast Asia Mid-East / Africa Australia / New Zealand China / Hong Kong World Wide |
| Main Products: | TECPEL Quality Test Instruments Taiwan - Temperature Meter, Multimeter, Thermometers, Clamp Meter, Measuring Instrument, Ph Meter, Sound Level Meter. |
| No. of Employee: | over 10 |
| Location: | Taiwan |
| Factory: | Taipei, Taiwan |
FAQ
How to order ?
TECPEL sells product through international distributors over 30 countries. For the countries that we don't have distributors there, we can quote you and ship goods directly.
Send us an inquiry and we assure you that our staff is made up of professional team that will help make your TECPEL experience a pleasant one.
After receiving your inquiry, we will send a quotation or proforma invoice to confirm our delviery and price within two working days.
Once it is approved by you, you can send the payment via T/T remittacne in advance or by Master or Visa credit card. Simply fill our the order form at
our home page. Duly sign it and send it back by fax 886-2-2737-3343. After receiving authentification from our bank, we can send goods in a few days as per our P/I confirmation.
What is warranty period ? Two years for this model dmm-8007.
___1. Each TECPEL product is warranted to be free from defects in material and workmanship under normal use for a period of one year. The warranty period is controlled by the documents furnished with each product and begins on the date of shipment. This warranty extends only to the original buyer or end-user customer of TECPEL and does not apply to fuses, disposable batteries or to any product which, in TECPEL's opinion, has been misused, altered, neglected or damaged by accident or abnormal conditions of operation or handling.
___2. TECPEL's warranty obligation is limited to refund of the purchase price or replacement of a defective product which is returned to TECPEL within the warranty period. TECPEL assumes no risk for damage in transit.
___3. If repair or re-adjustment is necessary and has not been the result of abuse or misuse within the warranty period, please return freight prepaid and rectifications of the deviation will be carried out without charge. However, if the product problems are examined due to consumer misuse, rectifications charges will be incurred. Out of warranty products will be charged accordingly.
