Характеристики



Tilting washer



  • Big touchscreen with multi-language adopted, the whole course of pre-washing, sterilizing, rinsing, bleaching and extracting can be performed automatically.

  • It has a through drum without barrier. Easy for operator to load and unload.

  • Opening, closing, tilting and unloading are performed automatically.

  • All control valves are pneumatically controlled so that the action is quick and stable.

  • Double-pipe rear drainage structure, free of pollution to the environment.

  • The machine is of high rust resistance and long service life as a result of the top quality of stainless steel.

  • Equipped with inverter, the machine has the advantages of energy saving and stable running. For high extraction, there are four speeds available according to different materials.










































































































































































Item



Unit



XGQ-100FQ



XGQ-160FQ



XGQ-200FQ



Rated capacity



Kg



100



160



200



Drum D×L



mm



1240*882



1460*1032



1600*1188



Case D×L



mm



1324*953



1544*1104



1718*1237



Motor power



kw



7.5


22

30



Washing speed



rpm



30


27

25



Balancing speed



rpm



60


55

52



Speed of mid-extract



rpm



350


300

290



Speed of hi-extract



rpm



680


630

620



Tilting angle while unloading



α



18


15

15



Steam pipe (ID)



mm



25


40

40



Cold/hot water pipe (ID)



mm



40


50

50



Exhaust water pipe (OD)



mm



114


114

114



Compressed air pipe(ID)



mm



8


8

8



Water inlet pressure



Mpa



0.2-0.4


0.2-0.4

0.2-0.4



Steam pressure



Mpa



0.4-0.6


0.4-0.6

0.4-0.6



Compressed air pressure



Mpa



0.4-0.6


0.4-0.6

0.4-0.6



Water consumption per cycle



m3



1435


2000

2400



Power consumption per cycle



Kw·h



2.4


2.2

2.6



Steam consumption per cycle



Kg



60


70

85



Air compressor (flow)



m3/min



0.1


0.013

0.13



Dimensions


(L×W×H)



mm



2020*1690*2050


2370*1945*2220

2583*2140*2302



Weight



Kg



3540


5420

6528






12345
