Китай высокое качество гидравлический Стандартный латунный шаровой кран средней

Описание и отзывы

Трекер стоимости

Характеристики





Brass Valves
Model	1.pc ball valve 2.pcs ball valve 3.mini ball valve
Joint method	(FF,MM,FM)Threaded,Butt-Welded,Clamped-Package,Flange ball valve
Surface	Nickel, Brass, Chrome
Size Range	1/2"3/4",1",11/4",11/2",2",21/2",3",31/1",4"5",6"
Working pressure	Forged, Casting
Working Temperature	PTFE≤150°C PPL≤300°C Carbon Fibre≤350°C
Applicable Medium	Water/Oil/Gas
Bore/port	Standard Bore,Full Bore,Half Bore,Reducing Bore
Threaded	NPT,BSPT,DIN2999,DIN259, ISO228
Material Speciafications
Body	Brass,Stainless Steel,Carbon Steel
Bonnet/cap	Brass
Ball	Brass
Ball seat	EPDM, PTFE
Thrust washer	PTFE
Stem	Steel, Brass
"O"Ring	PTFE
Handle/lever	Steel,Alloy,Carbon Steel, Iron,Stainless Steel
Handle/lever function	(Optional)Locking device handle
Handle/lever shape	Butterfly,Flat,Drawn
Handle/lever Cover	PTFE
Seal gasket	PTFE
Stem packing(up,middle,bottom)	PTFE
Screw/Blot	304
Nut	Iron,304
stem washer	Brass
MM / FM Thread	Thread to ISO228/1, BSP, NPT, etc
Applications	Steam, air, gas and oil pipes or for many other fluids
